Airtac SAID100 Double Rod Cylinder SAID100AX260
2. Patented asymmetric bidirectional sealing structure with integrated oil reservoir for compact dimensions and enhanced lubrication retention
3. H-shaped aluminum alloy barrel with rodless design improves corrosion resistance, featuring machined sensor mounting grooves for tool-free installation
4. Precision adjustable cushioning mechanism ensures smooth end-stroke deceleration
5. Available in multiple bore sizes with comprehensive mounting accessories portfolio
6. High-temperature resistant sealing materials enable extended operating range (0-150℃)
Category: Double Rod Cylinder , Brand: AirTAC , Series: SAID100
AirTAC SAID100AX260 Twin Rod Cylinder Specifications
- Model: SAID100AX260
- Type: Double-acting twin rod cylinder
- Bore size: Ø10mm (0.39")
- Stroke: 260mm (10.24")
- Operating pressure: 0.15–0.8 MPa (21.7–116 PSI)
- Cushioning: Adjustable elastic cushion (both ends)
- Mounting type: Basic fixed mounting (ISO 15552 standard)
- Rod diameter: Ø4mm (0.16") × 2 rods
- Material: Aluminum alloy barrel, hardened chrome-plated piston rods
- Temperature range: -20℃ to 80℃ (-4°F to 176°F)
- Protection rating: IP40 (dust protected)
- Port size: 1/8" NPT (G1/8 optional)
- Weight: 2.3kg (5.07 lbs)
- Dimensions: 360mm(L) × 40mm(W) × 50mm(H) (14.17" × 1.57" × 1.97")
- Seal material: High-grade NBR with wear-resistant ring
Precision twin rod pneumatic cylinder designed for applications requiring enhanced lateral rigidity and synchronized motion control. Features dual chromium-plated piston rods for improved alignment stability and reduced rod deflection under side loads. The symmetrical structure minimizes torque generation during operation, making it ideal for precision clamping and guided pushing applications.
- Semiconductor wafer handling robots
- Precision alignment stages in optical equipment
- Multi-axis material transfer systems
- CNC machine tool fixture mechanisms
- Automated inspection device positioning
Installation note:
Ensure proper rod alignment using alignment couplings when integrating with linear guides.
Lubricate with ISO VG32 hydraulic oil during initial installation. Avoid lateral forces exceeding 15N on rod ends.
| Property | Property Value |
|---|---|
| sku | SAID100AX260 |
| Seal Material | Polyurethane |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT 1/2 |
| Magnet | Non-magnetic |
| Cushion Stroke | <36mm> |
| Bore Diameter | 100mm |
| Stroke | 260mm |
