Airtac SAID100 Double Rod Cylinder SAID100AX260S
The AirTAC Airtac SAID100 Double Rod Cylinder SAID100AX260S is a genuine double-acting ISO 15552 profile-barrel air cylinder with a Ø100mm bore and 260mm stroke, G1/2 air ports and adjustable end cushioning. Its standardized mounting interface makes it a drop-in replacement for other ISO 15552 cylinders in automation lines.
- BoreØ100 mm
- Stroke260 mm
- Port sizeG1/2
- Acting typeDouble acting
- Rod threadM20×1.5
- CushionAdjustable, 36 mm
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac SAID100 Double Rod Cylinder SAID100AX260S
The AirTAC SAID100X260-S is a double-acting, double-rod ISO 15552 profile cylinder featuring a 100mm bore and 260mm stroke. A single piston drives a rod out of both end covers, yielding perfectly symmetric thrust. Because the annulus area is identical on both sides, it delivers 3681 N of force at 0.5 MPa in both extend and retract directions.
This unit includes a magnet (-S) for use with AirTAC CMSE reed and DMSE solid-state sensors, which drop into the extruded aluminum barrel grooves on both sides. The rods are made of SUS420J2 stainless steel for superior corrosion resistance, and fluid connections use PT tapered threads. The rear rod extension is ideal for mounting a secondary cam, position flag, or driving a second mechanism.
Airtac SAID100 Double Rod Cylinder SAID100AX260S Technical Specifications
| Model | Airtac SAID100 Double Rod Cylinder SAID100AX260S |
|---|---|
| Series | SAI ISO 15552 profile cylinder |
| Bore size | Ø100 mm |
| Stroke | 260 mm |
| Acting type | Double acting |
| Port size | G1/2 |
| Rod thread | M20×1.5 |
| Fluid | Air (filtered by 40µm element) |
|---|---|
| Operating pressure | 0.15 – 1.0 MPa |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C |
| Speed range | 30 – 800 mm/s |
| Cushion | Adjustable, 36 mm |
| Max stroke | Up to 1500 mm |
Specifications follow the official AirTAC SAI series datasheet and ISO 15552 dimensions. Confirm against the product label before installation. Port options: G (BSPP) / NPT.
Theoretical Output Force (Ø100mm)
| Pressure | Push force | Pull force |
|---|---|---|
| 0.5 MPa | 3927 N | 3682 N |
| 0.7 MPa | 5498 N | — |
| Max (@1.0 MPa) | 801 kgf | |
Actual usable force is lower than theoretical due to friction and back-pressure. Size with a safety margin.
Model Code: Airtac SAID100 Double Rod Cylinder SAID100AX260S
| SAI | ISO 15552 profile-barrel cylinder series. |
|---|---|
| 100 | Bore size in mm. |
| ×260 | Stroke length in mm. |
| -S | Optional built-in magnet for sensor position sensing. |
Related SAI-family variants: SAID (double rod), SAIJ (adjustable stroke), SAIL (with lock), SAIF (with valve), BSAI (enclasp / clamp-lock), and SAI-S with built-in magnet. Rod material: carbon steel (blank) / SUS420J2 (A) / SUS304 (B); seals: TPU (blank) / Viton H / NBR N.
Where the Airtac SAID100 Double Rod Cylinder SAID100AX260S Is Used
Symmetric Force Transfer
Drives a shuttle mechanism where equal push and pull forces (3681 N at 0.5 MPa) are critical for consistent bi-directional cycling.
Anti-Rotation Slides
The twin-rod design prevents piston rotation, guiding precision slides or tooling platforms without needing an external guide rail.
Rear-Tool Actuation
The protruding rear rod simultaneously operates a secondary valve or triggers a CMSE/DMSE position sensor at the back of the assembly.
Is the Airtac SAID100 Double Rod Cylinder SAID100AX260S the Right Cylinder?
Choose this 100mm bore when a smaller 80mm bore (providing 2268 N at 0.5 MPa) lacks sufficient thrust, or step down from a 125mm bore if you need to save space and weight. The twin-rod architecture is selected over a single-rod SAI when an application requires dual-side guidance, anti-rotation stability, or rear-rod position sensing. Note that a plain SAID does not hold its load when air is lost; for fail-safe holding, consider an external rod lock or the BSAID clamp-lock variant.
At 260mm stroke, the unsupported rod length is moderate, but for any stroke of 300mm or more, you should add an external guide to prevent rod-bearing bending under side loads. This model is dimensionally interchangeable per ISO 15552, offering a drop-in replacement for other ISO 15552 double-rod cylinders. Configure your setup using the PT G1/2 port, Basic/FA/LB/TC/FTC/TCM1/TCM2 mountings, and the integrated -S magnet.
Quick checklist
- ✓ Required force at your working pressure
- ✓ Stroke and mounting space
- ✓ Port/thread type (PT/NPT/G)
- ✓ Magnet (-S) for sensors?
- ✓ Side load — consider a guided cylinder
Installation & Maintenance Notes
- check Use clean air filtered to 40µm or finer.
- check Keep within 0.15 – 1.0 MPa operating pressure.
- check Avoid side load on the piston rod.
- check Adjust end cushion screws for smooth stops.
- check Use correct mounting accessory (FA/FB/CA/CB/LB/TC).
- check Installation by qualified personnel per AirTAC docs.
Airtac SAID100 Double Rod Cylinder SAID100AX260S FAQ
Because the rod occupies both sides of the piston, the effective area is identical in both directions. It provides 3681 N at 0.5 MPa, 5153 N at 0.7 MPa, and 6626 N at 0.9 MPa for both extend and retract strokes.
Yes, the SAID100X260-S is a true ISO 15552 profile cylinder with PT G1/2 ports. It is dimensionally interchangeable with other ISO 15552 double-rod cylinders, provided you use the correct mounting accessories from the SAID set (Basic, FA, LB, TC, FTC, TCM1, TCM2).
