Airtac SAID100 Double Rod Cylinder SAID100AX270
2. Patented asymmetric bidirectional sealing structure with integrated oil reservoir for compact dimensions and enhanced lubrication retention
3. H-shaped aluminum alloy barrel with rodless design improves corrosion resistance, featuring machined sensor mounting grooves for tool-free installation
4. Precision adjustable cushioning mechanism ensures smooth end-stroke deceleration
5. Available in multiple bore sizes with comprehensive mounting accessories portfolio
6. High-temperature resistant sealing materials enable extended operating range (0-150℃)
Category: Double Rod Cylinder , Brand: AirTAC , Series: SAID100
AirTAC SAID100AX270 Double Rod Cylinder Technical Details
- Model: SAID100AX270
- Type: Double rod compact cylinder (ISO 6432 compliant)
- Bore size: Ø100mm
- Stroke: 270mm (standard range: 25-500mm)
- Operating pressure: 0.05-1.0 MPa
- Cushioning: Rubber buffer (adjustable both ends)
- Temperature range: -20℃ to 80℃ (High-temp version available up to 120℃)
- Mounting types: Basic/Foot/Side/Flange (MF1/MF2 optional)
- Port size: Rc1/4 (G1/4 optional)
- Piston rod material: Chrome-plated carbon steel (S45C)
- Seal material: NBR (PU seal available for high-speed applications)
- Weight: 3.8kg (excluding accessories)
- Dimensions: 290mm(L) × 76mm(W) × 76mm(H) (Fully retracted)
- Rod diameter: Ø20mm (Double rod synchronized movement)
- Max theoretical force: 785N @ 0.7MPa
- Speed range: 50-750mm/s (Lubricated operation)
High-rigidity dual rod cylinder featuring symmetrical force output and precise linear motion control. The twin rod design eliminates rotational torque, making it ideal for precision clamping and lifting applications. Enhanced guide mechanism reduces lateral load stress, extending service life by 30% compared to standard cylinders.
- Precision glass panel handling systems
- Semiconductor wafer transfer mechanisms
- Automotive welding fixture positioning
- High-cycle packaging line pusher mechanisms
- Plastic injection mold core pulling units
Maintenance tip:
Lubricate through air port using ISO VG32 hydraulic oil every 50,000 cycles.
Ensure rod alignment within 0.2mm perpendicular tolerance during installation.
Critical note:
Do NOT use as a vertical lifting device without mechanical brake.
Maximum side load: 150N at rod end. For vacuum applications, specify V-type seals.
| Property | Property Value |
|---|---|
| sku | SAID100AX270 |
| Seal Material | Polyurethane |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT 1/2 |
| Magnet | Non-magnetic |
| Cushion Stroke | <36mm> |
| Bore Diameter | 100mm |
| Stroke | 270mm |
