Airtac SAID100 Double Rod Cylinder SAID100AX275S
2. Patented asymmetric bidirectional sealing structure with integrated oil reservoir for compact dimensions and enhanced lubrication retention
3. H-shaped aluminum alloy barrel with rodless design improves corrosion resistance, featuring machined sensor mounting grooves for tool-free installation
4. Precision adjustable cushioning mechanism ensures smooth end-stroke deceleration
5. Available in multiple bore sizes with comprehensive mounting accessories portfolio
6. High-temperature resistant sealing materials enable extended operating range (0-150℃)
Category: Double Rod Cylinder , Brand: AirTAC , Series: SAID100
AirTAC SAID100AX275S Twin Shaft Cylinder Technical Details
- Full Model Code: SAID100AX275S
- Series: SAID Standard Twin Shaft
- Bore Size: Ø100mm (3.94")
- Stroke: 275mm (10.83")
- Structure: Twin shaft double-acting (piston rods at both ends)
- Operating Pressure: 0.1-0.9 MPa (14.5-130.5 PSI)
- Cushioning: Adjustable pneumatic cushion at both ends
- Mounting: Side mounting with 4x M8 threaded holes (ISO 15552 standard)
- Tube Material: Aluminum alloy with hard anodized surface
- Rod Material: Chrome-plated steel (SUS304 equivalent)
- Seals: NBR (Nitrile) standard, optional Viton for high temp
- Operating Temperature: -20℃ to +80℃ (-4°F to +176°F)
- Lubrication: Pre-lubricated (relubrication required every 2,000km stroke)
- Weight: 7.8kg (17.2lbs) ±3%
- Dimensions (L×W×H): 375×140×140mm (14.76"×5.51"×5.51")
- Rod Diameter: Ø25mm (0.98") per shaft
- Protection Class: IP65 (dust-tight & protected against water jets)
- Piston Speed: 50-700mm/s (with cushioning engaged)
High-rigidity twin rod cylinder engineered for precision linear motion in heavy-duty applications. Features synchronized dual piston rods that eliminate rotational torque while maintaining parallel alignment under load. The hardened cylinder tube and triple-lip rod seals ensure extended service life in high-cycle operations (up to 2,000km maintenance interval). Includes magnetic piston for position sensing compatibility.
- Press machine ejector systems requiring anti-rotation stability
- Automated welding fixture positioning
- Glass handling equipment in photovoltaic panel production
- Die-casting machine core-pulling mechanisms
- Automotive wheel hub pressing stations
Installation Best Practices:1. Use precision alignment jigs during mounting to prevent side load
2. Maintain 0.5-1mm clearance between rods and external guides
3. For vertical mounting, install air bleeder at upper port
4. Apply Molykote G-5007 grease during relubrication
Critical Note:Requires 40μm filtration and oil mist lubrication (ISO VG32 equivalent). Avoid using in environments with phosphate ester-based hydraulic fluids.
| Property | Property Value |
|---|---|
| sku | SAID100AX275S |
| Seal Material | Polyurethane |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT 1/2 |
| Magnet | S-Magnetic |
| Cushion Stroke | <36mm> |
| Bore Diameter | 100mm |
| Stroke | 275mm |
