Airtac SAID100 Double Rod Cylinder SAID100AX280
2. Patented asymmetric bidirectional sealing structure with integrated oil reservoir for compact dimensions and enhanced lubrication retention
3. H-shaped aluminum alloy barrel with rodless design improves corrosion resistance, featuring machined sensor mounting grooves for tool-free installation
4. Precision adjustable cushioning mechanism ensures smooth end-stroke deceleration
5. Available in multiple bore sizes with comprehensive mounting accessories portfolio
6. High-temperature resistant sealing materials enable extended operating range (0-150℃)
Category: Double Rod Cylinder , Brand: AirTAC , Series: SAID100
AirTAC SAID100AX280 Dual-Axis Cylinder Technical Specifications
- Model: SAID100AX280
- Type: Dual-axis guided cylinder with magnetic piston
- Bore size: 100mm
- Stroke: 280mm (standard, customizable 50-500mm)
- Operating pressure: 0.05-1.0 MPa
- Temperature range: -20℃ to 80℃
- Cushion type: Adjustable air cushion (both ends)
- Mounting type: Standard MF1 flange with multiple accessory options
- Port size: G3/8 (NPT1/4 optional)
- Piston rod thread: M20×1.5
-
Material:
- Tube: Aluminum alloy hard oxidation
- Piston rod: Chrome-plated steel
- End caps: High-strength aluminum
- Weight: 8.7kg ±2% (without accessories)
-
Dimensions:
- Length: 645mm (stroke 280mm + cylinder body)
- Width: 180mm (guide rail center distance)
- Height: 130mm (overall profile)
- Protection class: IP54 (standard), IP67 optional
- Lubrication: Pre-lubricated (DOP mist compatible)
Industrial-grade dual-axis cylinder combining thrust and precise linear guidance in one compact unit. Features hardened guide rails with adjustable preload for minimal deflection (≤0.05mm/m). Integrated sensor slots support magnetic or mechanical position detection. Anti-rotation design maintains orientation stability under heavy side loads up to 1,200N.
- Automated material handling systems
- Precision press-fit operations in electronics assembly
- Vertical lifting mechanisms for packaging lines
- Automotive welding fixture positioning
- Glass panel transfer systems
- Align guide rails within 0.2mm/m parallel tolerance
- Use flexible couplings for stroke >300mm
- Apply low-viscosity lubricant (ISO VG32) every 5,000km operation
- Maintain 20mm clearance around cylinder for heat dissipation
Critical Tip: Always install auxiliary supports when stroke length exceeds 400mm or horizontal mounting with >50kg payload. Use alignment jigs during installation to prevent guide rail binding.
| Property | Property Value |
|---|---|
| sku | SAID100AX280 |
| Seal Material | Polyurethane |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT 1/2 |
| Magnet | Non-magnetic |
| Cushion Stroke | <36mm> |
| Bore Diameter | 100mm |
| Stroke | 280mm |
