Airtac SAID100 Double Rod Cylinder SAID100AX280S
2. Patented asymmetric bidirectional sealing structure with integrated oil reservoir for compact dimensions and enhanced lubrication retention
3. H-shaped aluminum alloy barrel with rodless design improves corrosion resistance, featuring machined sensor mounting grooves for tool-free installation
4. Precision adjustable cushioning mechanism ensures smooth end-stroke deceleration
5. Available in multiple bore sizes with comprehensive mounting accessories portfolio
6. High-temperature resistant sealing materials enable extended operating range (0-150℃)
Category: Double Rod Cylinder , Brand: AirTAC , Series: SAID100
AirTAC SAID100AX280S Twin Shaft Cylinder Technical Details
- Model: SAID100AX280S
- Type: Double rod ISO pneumatic cylinder
- Bore size: 100mm (±0.5mm tolerance)
- Stroke: 280mm (adjustable cushioning)
- Operating pressure: 0.05–1.0 MPa
- Piston rod diameter: 25mm (hard chrome-plated)
- Port size: G1/2 (BSPP thread)
- Mounting type: Basic front flange (ISO 15552 standard)
- Cushioning: Adjustable air cushion (both ends)
- Cylinder material: Aluminum alloy (anodized surface)
- Operating temperature: -20℃ to 80℃
- Weight: 12.5kg (±5%)
- Dimensions:
- Total length: 628mm (stroke + cylinder body)
- Body width: 120mm (including mounting flanges)
- Height: 142mm (rod center to base)
- Seal material: NBR (nitrile rubber)
- Protection class: IP65 (standard wiper seal)
High-rigidity twin rod cylinder designed for precision linear motion requiring symmetrical force distribution. Features dual piston rods that eliminate rotational torque, making it ideal for applications demanding exceptional side load capacity. Includes magnetic piston (D-M9 sensor compatible) for position feedback.
- Automated palletizing systems (horizontal pushing/pulling)
- Precision glass panel handling equipment
- Heavy-duty clamping fixtures in CNC machining
- Automotive assembly line positioning arms
- Paper roll handling in printing machinery
Installation guidance:
For vertical mounting, use reinforced rod-end supports. Lubricate through port lubrication points every 500km of stroke operation. Maintain 0.3-0.6 MPa pressure for optimal seal performance.
Critical note:
Avoid axial misalignment exceeding 0.5mm during installation. Use flexible couplings when connecting to guided mechanisms. Maximum side load capacity: 1,200N at mid-stroke.
| Property | Property Value |
|---|---|
| sku | SAID100AX280S |
| Seal Material | Polyurethane |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT 1/2 |
| Magnet | S-Magnetic |
| Cushion Stroke | <36mm> |
| Bore Diameter | 100mm |
| Stroke | 280mm |
