Airtac SAID125 Double Rod Cylinder SAID125AX115S
2. Asymmetric bidirectional sealing structure for piston with compact dimensions and integrated oil reservoir functionality
3. Cross-section aluminum alloy tube with tie-rod-free design for superior corrosion resistance; Integrated sensor mounting grooves enable fast and secure sensor installation
4. Smooth adjustable cushioned stroke control mechanism
5. Multiple bore sizes and mounting accessories available for customizable configurations
6. High-temperature resistant seals (operating range: 0~150°C)
Category: Dual Rod Cylinders , Brand: AIRTAC , Series: SAID125
AirTAC SAID125AX115S Dual Rod Cylinder Technical Specifications
- Model: SAID125AX115S
- Type: Double rod air cylinder (ISO 6432 compliant)
- Bore size: 32mm (±0.1mm tolerance)
- Stroke: 115mm (customizable up to 500mm)
- Rod diameter: 12mm (chrome-plated steel)
- Operating pressure: 0.05-1.0 MPa
- Temperature range: -20℃ to 80℃
- Port size: G1/8 (NPT1/8 optional)
- Cushioning: Adjustable air cushion at both ends
- Seal material: HNBR/Nitrile rubber (FDA compliant option available)
- Protection rating: IP40 (IP67 with optional wiper seals)
- Weight: 1.6kg (excluding accessories)
- Dimensions:
- Total length: 243mm (stroke 115 + cylinder body 128)
- Body width: 40mm
- Height with rods: 52mm
- Mounting center distance: 25mm
Precision double rod pneumatic cylinder featuring synchronized movement and enhanced lateral load capacity. The twin rod design ensures symmetrical force distribution, minimizing rotational torque during operation. Anodized aluminum construction with hardened stainless steel guide rods provides corrosion resistance in humid environments. Includes magnetic piston for sensor compatibility (SM/SD series sensors optional).
- Precision clamping fixtures in CNC machining centers
- Simultaneous lifting mechanisms in material handling
- Web tension control in printing/packaging lines
- Position-stabilized platforms in semiconductor manufacturing
- Synchronized door operation in cleanroom environments
Installation guidelines:
Maintain 0.05mm maximum misalignment during mounting. Use locknuts with 12-15Nm torque.
For vertical installations, install air vents upward. Lubricate with ISO VG32 hydraulic oil
if operating below 0.3MPa. Recommend replacing seals after 3,000km cumulative travel.
| Property | Property Value |
|---|---|
| sku | SAID125AX115S |
| Seal Material | Polyurethane |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | PT 1/2 |
| Magnet | S-Magnetic |
| Cushion Stroke | <40mm> |
| Bore Diameter | 125mm |
| Stroke | 115mm |
