Airtac SAID125 Double Rod Cylinder SAID125AX120
2. Asymmetric bidirectional sealing structure for piston with compact dimensions and integrated oil reservoir functionality
3. Cross-section aluminum alloy tube with tie-rod-free design for superior corrosion resistance; Integrated sensor mounting grooves enable fast and secure sensor installation
4. Smooth adjustable cushioned stroke control mechanism
5. Multiple bore sizes and mounting accessories available for customizable configurations
6. High-temperature resistant seals (operating range: 0~150°C)
Category: Dual Rod Cylinders , Brand: AIRTAC , Series: SAID125
AirTAC SAID125AX120 Dual Rod Cylinder Specifications
- Model: SAID125AX120
- Type: Double rod cylinder (ISO 15552 standard)
- Bore size: Ø125 mm
- Stroke: 120 mm (customizable up to 2,000 mm)
- Operating pressure: 0.05–1.0 MPa
- Piston speed: 50–800 mm/s
- Cushioning: Adjustable pneumatic cushion (both ends)
- Mounting type: Basic non-magnetic switch version (NFSC optional)
- Port size: G1/2 (NPT1/2 optional)
- Material:
- Tube: Hard anodized aluminum alloy
- Piston rod: Chrome-plated stainless steel (SUS304)
- Seals: NBR standard (FKM/PU available)
- Weight: 7.8 kg (±3%)
- Dimensions:
- Length: 328 mm (stroke-dependent)
- Width: 156 mm (mounting face to rod end)
- Height: 156 mm (including mounting hardware)
- Temperature range: -20℃ to 80℃ (with FKM seals)
- Lubrication: Pre-lubricated (recommended oil: ISO VG32)
High-rigidity dual rod cylinder designed for precision linear motion applications requiring enhanced lateral load capacity. Features symmetrical force distribution through twin piston rods, reducing bending moments by 40% compared to single-rod models. The through-rod design ensures position stability in vertical installations. Optional magnetic piston version (SAID125AX120-M) available for position feedback.
- Automated welding fixture positioning
- Press brake tooling adjustment systems
- Heavy-duty conveyor gate control
- Plastic injection mold clamping
- Solar panel tilt mechanism actuation
Installation notes:
- Align rods within 0.2mm/m parallelism tolerance
- Use floating brackets for multi-cylinder synchronization
- Apply anti-vibration pads in high-frequency applications (>2Hz)
- Lubricate rod surfaces weekly in dusty environments
| Property | Property Value |
|---|---|
| sku | SAID125AX120 |
| Seal Material | Polyurethane |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | PT 1/2 |
| Magnet | Non-magnetic |
| Cushion Stroke | <40mm> |
| Bore Diameter | 125mm |
| Stroke | 120mm |
