Airtac SAID125 Double Rod Cylinder SAID125AX120S
2. Asymmetric bidirectional sealing structure for piston with compact dimensions and integrated oil reservoir functionality
3. Cross-section aluminum alloy tube with tie-rod-free design for superior corrosion resistance; Integrated sensor mounting grooves enable fast and secure sensor installation
4. Smooth adjustable cushioned stroke control mechanism
5. Multiple bore sizes and mounting accessories available for customizable configurations
6. High-temperature resistant seals (operating range: 0~150°C)
Category: Dual Rod Cylinders , Brand: AIRTAC , Series: SAID125
AirTAC SAID125AX120S Dual Rod Cylinder Specifications
- Model: SAID125AX120S
- Type: Double-acting cylinder with guide rods
- Bore size: Ø125 mm
- Stroke: 120 mm (customizable: 25-500 mm)
- Operating pressure: 0.05-1.0 MPa
- Cushioning: Adjustable buffer (both ends)
- Mounting type: Basic type (MF1) with front flange
- Port size: Rc1/2 (G1/2 optional)
- Piston rod diameter: Ø32 mm chromium-plated steel
- Material: Aluminum alloy barrel, hardened guide rods
- Temperature range: -20℃ to 80℃
- Weight: 5.8 kg (excluding accessories)
- Dimensions:
- Total length (L): 336 mm (base length 216mm + stroke)
- Width (W): 172 mm (guide rod center distance)
- Height (H): 158 mm (flange base to top)
- Seal material: NBR standard (PU optional)
- Rod bearing: Self-lubricating composite material
- ISO standard: 15552 compliant
Heavy-duty dual-rod cylinder engineered for precision linear motion requiring enhanced rigidity and anti-rotation performance. Features twin 32mm guide rods that provide 10x higher lateral load capacity compared to single-rod cylinders. Integrated mounting slots allow direct sensor installation for position feedback.
- Precision press mechanisms in stamping machines
- Vertical lifting platforms with side load resistance
- Automated welding fixture positioning systems
- Glass handling equipment requiring parallel motion
- Plastic injection molding ejector units
Installation guidelines:
Use alignment jigs during mounting to ensure parallel installation.
Apply ISO VG32 hydraulic oil for initial lubrication.
Maximum side load capacity: 1,960N at mid-stroke.
Recommend using ARD20 series rod locks for vertical applications.
| Property | Property Value |
|---|---|
| sku | SAID125AX120S |
| Seal Material | Polyurethane |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | PT 1/2 |
| Magnet | S-Magnetic |
| Cushion Stroke | <40mm> |
| Bore Diameter | 125mm |
| Stroke | 120mm |
