Airtac SAID125 Double Rod Cylinder SAID125AX125
2. Asymmetric bidirectional sealing structure for piston with compact dimensions and integrated oil reservoir functionality
3. Cross-section aluminum alloy tube with tie-rod-free design for superior corrosion resistance; Integrated sensor mounting grooves enable fast and secure sensor installation
4. Smooth adjustable cushioned stroke control mechanism
5. Multiple bore sizes and mounting accessories available for customizable configurations
6. High-temperature resistant seals (operating range: 0~150°C)
Category: Dual Rod Cylinders , Brand: AIRTAC , Series: SAID125
AirTAC SAID125AX125 Double Rod Cylinder Technical Specifications
- Model: SAID125AX125 (DIN/ISO 15552 Standard)
- Bore size: Ø125 mm
- Stroke range: 25-2000 mm (customizable)
- Operating pressure: 0.05-1.2 MPa
- Cushioning type: Adjustable air cushion (both ends)
- Piston speed: 50-1000 mm/s
- Ambient temperature: -20℃ to 80℃
- Port size: G1/2
- Rod diameter: Ø35 mm (chrome-plated steel)
- Seal material: NBR/PU (oil & wear resistant)
- Weight: 14.8 kg (base model, 100mm stroke)
- Dimensions (L×W×H):
- Standard stroke 100mm: 498mm × 155mm × 155mm
- Add 4.7mm length per 1mm stroke extension
- Mounting options: MF1/MF2 flange, MX3/MX5 side mounts
- Accessories: Magnetic switch (D-A93), rod lock kit
Industrial-grade double rod cylinder designed for heavy-duty applications requiring precise linear motion and anti-rotation stability. Features symmetrical force distribution through dual piston rods, hardened guide bearings, and IP67 protection rating. Optional position detection with embedded sensor slots. Requires ISO VG32 hydraulic oil lubrication for optimal performance.
- Automotive welding fixture positioning
- Steel coil handling systems
- Plastic injection molding ejectors
- Paper mill roller pressing mechanisms
- Precision CNC machine tool clamps
Installation guidelines:
Use alignment jigs during mounting to prevent side load. For strokes >500mm,
install intermediate rod supports. Lubricate every 3,000km of cumulative travel
or 6 months (whichever comes first). Avoid rapid pressure changes >0.5 MPa/sec.
| Property | Property Value |
|---|---|
| sku | SAID125AX125 |
| Seal Material | Polyurethane |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | PT 1/2 |
| Magnet | Non-magnetic |
| Cushion Stroke | <40mm> |
| Bore Diameter | 125mm |
| Stroke | 125mm |
