Airtac SAID125 Double Rod Cylinder SAID125AX135S
2. Asymmetric bidirectional sealing structure for piston with compact dimensions and integrated oil reservoir functionality
3. Cross-section aluminum alloy tube with tie-rod-free design for superior corrosion resistance; Integrated sensor mounting grooves enable fast and secure sensor installation
4. Smooth adjustable cushioned stroke control mechanism
5. Multiple bore sizes and mounting accessories available for customizable configurations
6. High-temperature resistant seals (operating range: 0~150°C)
Category: Dual Rod Cylinders , Brand: AIRTAC , Series: SAID125
AirTAC SAID125AX135S Dual Rod Cylinder Technical Details
- Model: SAID125AX135S
- Type: Double rod double acting cylinder
- Bore size: Ø125mm
- Stroke: 135mm
- Port size: 1/2" NPT (G1/2 optional)
- Operating pressure: 0.1–0.9 MPa
- Cushioning: Adjustable pneumatic cushion (both ends)
- Piston rod material: Chrome-plated carbon steel (HRC 45-50)
- Tube material: Hard anodized aluminum alloy
- Seals: NBR (standard) / PU (optional)
- Temperature range: -20℃ to 80℃
- Weight: 7.8kg (excluding accessories)
- Dimensions: 572mm(L) × 200mm(W) × 200mm(H)
- Mounting: Multiple options (MF2/MF4 flange, MP4/MP6 side mounts)
- Protection rating: IP65 (wipers included)
- Max lateral load: 450N at full extension
High-rigidity dual rod cylinder designed for precision linear motion with enhanced moment resistance. Features twin chrome-plated piston rods that provide exceptional alignment stability and load distribution. The hardened aluminum body with integrated mounting slots enables flexible installation configurations. Includes magnetic piston for position sensing compatibility.
- Precision press-fit operations in automotive assembly
- Heavy-duty clamping fixtures for CNC machining
- Vertical lifting mechanisms in logistics automation
- Parallel motion systems requiring synchronized movement
- Packaging machinery with side load challenges
Installation tip:
Maintain parallel alignment within 0.2mm/meter during mounting.
Use locknuts on both rod ends (M30×1.5 threads) for heavy loads.
Lubricate with ISO VG32 turbine oil before initial operation.
| Property | Property Value |
|---|---|
| sku | SAID125AX135S |
| Seal Material | Polyurethane |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | PT 1/2 |
| Magnet | S-Magnetic |
| Cushion Stroke | <40mm> |
| Bore Diameter | 125mm |
| Stroke | 135mm |
