Airtac SAID125 Double Rod Cylinder SAID125AX145S
2. Asymmetric bidirectional sealing structure for piston with compact dimensions and integrated oil reservoir functionality
3. Cross-section aluminum alloy tube with tie-rod-free design for superior corrosion resistance; Integrated sensor mounting grooves enable fast and secure sensor installation
4. Smooth adjustable cushioned stroke control mechanism
5. Multiple bore sizes and mounting accessories available for customizable configurations
6. High-temperature resistant seals (operating range: 0~150°C)
Category: Dual Rod Cylinders , Brand: AIRTAC , Series: SAID125
AirTAC SAID125AX145S Twin Rod Cylinder Technical Details
- Model Code: SAID125AX145S
- Type: Double-rod cylinder (ISO 15552 standard)
- Bore size: Ø125mm (±0.5mm tolerance)
- Stroke: 145mm (customizable range: 50-2000mm)
- Operating pressure: 0.05-1.2MPa
- Piston speed: 50-1000mm/s (lubricated)
- Cushioning: Adjustable hydraulic buffers (both ends)
- Port size: G1/2 (BSPP thread)
- Ambient temperature: -20℃ to 80℃
- Mounting: MF1/MF2/MF4 options (standard MF2 flange)
- Rod material: Hard chrome-plated carbon steel (S45C)
- Tube material: Anodized aluminum alloy
- Seal type: NBR + PU combination seals
- Weight: 12.8kg (excluding accessories)
- Dimensions:
- Body diameter: Ø136mm
- Stroke length: 145mm
- Total length: 445mm (calculated as L = base length + stroke)
- Rod diameter: Ø35mm (dual rods)
- Mounting hole spacing: 160×160mm
High-rigidity twin rod cylinder designed for heavy-load precision applications requiring exceptional moment resistance. Features dual chromium-plated piston rods with anti-rotation guidance, achieving ≤0.5mm/m parallel deviation. Integrated wear sensors optional. Requires ISO 8573-1:2010 Class 3-4-3 compressed air.
- Automated palletizing systems (food/beverage industry)
- Plastic injection molding machine ejectors
- Steel coil handling grippers
- Precision glass cutting platforms
- Battery module compression fixtures
Installation protocol:
Apply 32N·m torque to mounting bolts using cross-pattern tightening sequence.
Maintain 0.5-1mm/m alignment tolerance relative to load path. Lubricate with
ISO VG32 hydraulic oil during initial commissioning.
| Property | Property Value |
|---|---|
| sku | SAID125AX145S |
| Seal Material | Polyurethane |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | PT 1/2 |
| Magnet | S-Magnetic |
| Cushion Stroke | <40mm> |
| Bore Diameter | 125mm |
| Stroke | 145mm |
