Airtac SAID125 Double Rod Cylinder SAID125AX150
2. Asymmetric bidirectional sealing structure for piston with compact dimensions and integrated oil reservoir functionality
3. Cross-section aluminum alloy tube with tie-rod-free design for superior corrosion resistance; Integrated sensor mounting grooves enable fast and secure sensor installation
4. Smooth adjustable cushioned stroke control mechanism
5. Multiple bore sizes and mounting accessories available for customizable configurations
6. High-temperature resistant seals (operating range: 0~150°C)
Category: Dual Rod Cylinders , Brand: AIRTAC , Series: SAID125
AirTAC SAID125AX150 Twin Rod Cylinder Technical Details
- Model: SAID125AX150
- Type: ISO 15552 compliant twin rod pneumatic cylinder
- Bore size: Ø125mm ±0.5mm tolerance
- Stroke: 150mm (standard), customizable up to 2000mm
- Operating pressure: 0.1–0.9 MPa (14.5–130.5 PSI)
- Cushioning: Adjustable air cushion at both ends
- Port size: G1/2 (BSPP thread)
- Piston rod material: Hard chrome-plated steel (Ø32mm)
- Tube material: Anodized aluminum alloy (AL6063-T5)
- Seal type: NBR + PU combination seals
- Temperature range: -20℃ to +80℃ (dry air required below 0℃)
- Weight: 5.8kg ±3% (excluding accessories)
- Dimensions: 300mm(L) × 150mm(W) × 150mm(H)
- Rod end thread: M20×1.5 (male)
- Max speed: 500–800mm/s (with cushion engaged)
- ISO rating: 1,500km service life at 0.5MPa
- Protection class: IP65 (rod extended), IP40 (retracted)
High-rigidity twin rod cylinder designed for precision alignment applications requiring symmetrical force distribution. Features dual piston rods that eliminate rotational torque and maintain parallel movement under heavy side loads. Anti-corrosion treatment on all exposed surfaces makes it suitable for humid environments when paired with stainless steel hardware kit (optional).
- Automated palletizing systems with lateral stability requirements
- Press machine tooling alignment mechanisms
- Glass manufacturing conveyor positioning
- Automotive welding jig actuators
- Plastic injection molding ejection systems
Mounting guidelines:
Use M12 mounting bolts (grade 8.8 or higher) with spring washers.
Align within 0.2mm/m parallelism tolerance. Lubricate with ISO VG32
hydraulic oil during assembly. For vertical installations,
add external guide mechanism for load stabilization.
Critical note:
Avoid angular misalignment exceeding ±2°. When handling overhung loads,
calculate moment load using formula M = F×L ≤ 350 N·m (max).
Install shock absorbers for payloads above 120kg.
| Property | Property Value |
|---|---|
| sku | SAID125AX150 |
| Seal Material | Polyurethane |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | PT 1/2 |
| Magnet | Non-magnetic |
| Cushion Stroke | <40mm> |
| Bore Diameter | 125mm |
| Stroke | 150mm |
