Airtac SAID125 Double Rod Cylinder SAID125AX150S
2. Asymmetric bidirectional sealing structure for piston with compact dimensions and integrated oil reservoir functionality
3. Cross-section aluminum alloy tube with tie-rod-free design for superior corrosion resistance; Integrated sensor mounting grooves enable fast and secure sensor installation
4. Smooth adjustable cushioned stroke control mechanism
5. Multiple bore sizes and mounting accessories available for customizable configurations
6. High-temperature resistant seals (operating range: 0~150°C)
Category: Dual Rod Cylinders , Brand: AIRTAC , Series: SAID125
AirTAC SAID125AX150S Dual-Axis Cylinder Specifications
- Model: SAID125AX150S
- Type: Dual-axis guided cylinder (double rod)
- Bore size: Ø125mm
- Stroke: 150mm (standard options: 25-500mm)
- Operating pressure: 0.1-0.9 MPa
- Cushioning: Adjustable pneumatic cushion at both ends
- Mounting: Front/rear flange mounting (MF1/MF2 pattern)
- Port size: G1/2 (ISO228/1 standard)
- Temperature range: -20℃ to 80℃
- Cylinder tube material: Aluminum alloy with hard anodized surface
- Piston rod material: Chrome-plated steel (Cr-Mo alloy)
- Seal material: NBR/PU combination
- Weight: Approximately 7.8kg (without accessories)
- Dimensions: 298mm(L) × 125mm(W) × 125mm(H) (at mid-stroke position)
- Rod diameter: Ø25mm (both rods)
- Max lateral load: 850N
- ISO standard: 15552 compliant
High-rigidity dual-rod cylinder designed for precision linear motion requiring exceptional moment resistance. Features twin guide rods that eliminate rotation and maintain parallel alignment under heavy side loads. The hardened piston rods and dual cushioning system enable smooth operation in high-cycle applications (up to 3,000,000 cycles MTBF). Includes built-in magnet for position sensing compatibility.
- Automated welding fixture positioning systems
- Die-casting machine core-pulling mechanisms
- Heavy-duty material transfer elevators
- Precision glass cutting equipment
- Automotive wheel hub pressing stations
Installation note:
Ensure guide rods are parallel within 0.1mm/m tolerance during mounting.
Use locknuts with 25-30Nm torque for rod-end accessories. Lubricate with ISO VG32
hydraulic oil before initial operation. Install air filter regulator with
≤5μm filtration upstream.
| Property | Property Value |
|---|---|
| sku | SAID125AX150S |
| Seal Material | Polyurethane |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | PT 1/2 |
| Magnet | S-Magnetic |
| Cushion Stroke | <40mm> |
| Bore Diameter | 125mm |
| Stroke | 150mm |
