Airtac SAID125 Double Rod Cylinder SAID125AX155
2. Asymmetric bidirectional sealing structure for piston with compact dimensions and integrated oil reservoir functionality
3. Cross-section aluminum alloy tube with tie-rod-free design for superior corrosion resistance; Integrated sensor mounting grooves enable fast and secure sensor installation
4. Smooth adjustable cushioned stroke control mechanism
5. Multiple bore sizes and mounting accessories available for customizable configurations
6. High-temperature resistant seals (operating range: 0~150°C)
Category: Dual Rod Cylinders , Brand: AIRTAC , Series: SAID125
AirTAC SAID125AX155 Dual Rod Cylinder Technical Specifications
- Model: SAID125AX155
- Bore size: Ø125mm
- Stroke: 155mm (customizable 25-500mm)
- Operating pressure: 0.05-1.0 MPa
- Piston speed: 50-750 mm/s (cushioned)
- Temperature range: -20℃ to 80℃
- Cushioning: Adjustable elastic buffer + air cushion
- Mounting type: Basic fixed (ISO 15552 standard)
- Port size: G1/2 (NPT1/2 optional)
- Rod material: Hard chrome-plated carbon steel
- Tube material: Anodized aluminum alloy
- Seal type: NBR + PU hybrid seals
- Repeat positioning accuracy: ±0.2mm
- Weight: 8.7kg (bare cylinder)
- Dimensions: 465mm(L) × 160mm(W) × 160mm(H)
- Accessories: Optional magnetic switch (D-M9N series)
High-rigidity dual rod cylinder designed for precision alignment applications. Features twin piston rods that eliminate rotational torque and provide exceptional lateral load capacity (up to 650N). Integrated cushioning system reduces end-impact noise to <70dB. Pre-lubricated for maintenance-free operation.
- Automated palletizing systems requiring parallel motion
- Press brake tool positioning in metal fabrication
- Glass panel handling with vacuum end effectors
- Precision mold clamping mechanisms
- Automotive welding fixture positioning
Installation tip:
Maintain 0.05-0.1mm/mm alignment tolerance between rod ends and load.
Use flexible couplings for stroke-end force absorption. Lubricate rods monthly
in high-cycle applications (>500,000 cycles/year).
| Property | Property Value |
|---|---|
| sku | SAID125AX155 |
| Seal Material | Polyurethane |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | PT 1/2 |
| Magnet | Non-magnetic |
| Cushion Stroke | <40mm> |
| Bore Diameter | 125mm |
| Stroke | 155mm |
