Airtac SAID125 Double Rod Cylinder SAID125AX155S
2. Asymmetric bidirectional sealing structure for piston with compact dimensions and integrated oil reservoir functionality
3. Cross-section aluminum alloy tube with tie-rod-free design for superior corrosion resistance; Integrated sensor mounting grooves enable fast and secure sensor installation
4. Smooth adjustable cushioned stroke control mechanism
5. Multiple bore sizes and mounting accessories available for customizable configurations
6. High-temperature resistant seals (operating range: 0~150°C)
Category: Dual Rod Cylinders , Brand: AIRTAC , Series: SAID125
AirTAC SAID125AX155S Dual Rod Cylinder Technical Specifications
- Model Code: SAID125AX155S
- Type: ISO 6432 compliant dual rod cylinder
- Bore diameter: Ø125mm ±0.5μm precision honing
- Stroke: 155mm (customizable 50-500mm)
- Operating pressure: 0.1-0.9 MPa (1-9 bar)
- Cushioning: Adjustable hydraulic buffer (both ends)
- Piston rod material: Chrome-plated SCM435 steel
- Tube material: Hard-anodized 6063-T5 aluminum
- Seals: HNBR compound with wear-resistant guide rings
- Temperature range: -20℃ to 80℃ (dry air required below 0℃)
- Lubrication: Pre-lubricated (Optional oil-fog lubrication port)
- Weight: 5.8kg ±3% (without accessories)
- Dimensions: 338mm(L) × 175mm(W) × 175mm(H) (stroke extended)
- Rod diameter: Ø25mm dual rods (anti-rotation design)
- Mounting: Standard MF12 flange + integrated side mounting slots
- Port size: G1/2 ISO228 threads (BSPP)
- Position detection: Optional magnetic sensor groove (M9x1)
Industrial-grade dual rod cylinder engineered for precision linear motion requiring enhanced rigidity and alignment stability. Features symmetrical load distribution through parallel rods and hardened guide bushings, minimizing deflection during high moment load operations. Optional IP67-rated models available for washdown environments.
- Precision press-fit operations in automotive assembly
- Vertical lifting gates in material handling systems
- Simultaneous clamping mechanisms in CNC fixtures
- Parallel gripper actuation in robotic EOAT
- Packaging machine alignment correction systems
Installation guidelines:
Maintain 0.05mm/m alignment tolerance during mounting. Use flexible couplings when connecting to guided slides.
For strokes >300mm, install intermediate rod supports. Pre-charge buffer adjustment screws 1.5 turns from full close position.
| Property | Property Value |
|---|---|
| sku | SAID125AX155S |
| Seal Material | Polyurethane |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | PT 1/2 |
| Magnet | S-Magnetic |
| Cushion Stroke | <40mm> |
| Bore Diameter | 125mm |
| Stroke | 155mm |
