Airtac SAID125 Double Rod Cylinder SAID125AX95S
2. Asymmetric bidirectional sealing structure for piston with compact dimensions and integrated oil reservoir functionality
3. Cross-section aluminum alloy tube with tie-rod-free design for superior corrosion resistance; Integrated sensor mounting grooves enable fast and secure sensor installation
4. Smooth adjustable cushioned stroke control mechanism
5. Multiple bore sizes and mounting accessories available for customizable configurations
6. High-temperature resistant seals (operating range: 0~150°C)
Category: Dual Rod Cylinders , Brand: AIRTAC , Series: SAID125
AirTAC SAID125AX95S Twin Rod Cylinder Specifications
- Model: SAID125AX95S
- Type: Double-acting twin rod cylinder
- Bore size: Ø125mm (±0.5mm tolerance)
- Stroke: 95mm (adjustable cushioning)
- Operating pressure: 0.05-1.0 MPa
- Piston rod diameter: Ø32mm chrome-plated steel
- Port size: G1/2 (BSPP thread)
- Max thrust: 1,570N at 0.5MPa
- Temperature range: -20℃ to 80℃
- Seal material: NBR + PU combination
- Cushioning: Adjustable rubber buffers (both ends)
- Mounting: Standard ISO 15552 front flange
- Weight: 11.8kg (with magnetic switch)
- Dimensions: 318mm(L) × 170mm(W) × 170mm(H)
- Rod end threads: M20×1.5 (both rods)
- Protection rating: IP67 (wipers included)
High-rigidity twin rod cylinder designed for precision linear motion under heavy side loads. Features dual piston rods that eliminate rotational movement and improve moment resistance by 40% compared to standard cylinders. The symmetrical structure ensures balanced force distribution, with through-hole design allowing easy sensor mounting.
- Palletizing robot vertical lift mechanisms
- Die-casting machine core pull systems
- Automated welding fixture positioning
- Paper roll clamping in printing presses
- Glass panel transfer systems
Installation note:
Maintain parallel alignment within 0.2mm/m using precision levels during mounting.
Lubricate with ISO VG32 hydraulic oil if operating below 0℃. Allow 50mm clearance
behind rod ends for full stroke operation.
| Property | Property Value |
|---|---|
| sku | SAID125AX95S |
| Seal Material | Polyurethane |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | PT 1/2 |
| Magnet | S-Magnetic |
| Cushion Stroke | <40mm> |
| Bore Diameter | 125mm |
| Stroke | 95mm |
