Airtac SAID125 Double Rod Cylinder SAID125BX100
2. Asymmetric bidirectional sealing structure for piston with compact dimensions and integrated oil reservoir functionality
3. Cross-section aluminum alloy tube with tie-rod-free design for superior corrosion resistance; Integrated sensor mounting grooves enable fast and secure sensor installation
4. Smooth adjustable cushioned stroke control mechanism
5. Multiple bore sizes and mounting accessories available for customizable configurations
6. High-temperature resistant seals (operating range: 0~150°C)
Category: Dual Rod Cylinders , Brand: AIRTAC , Series: SAID125
AirTAC SAID125BX100 Dual Rod Cylinder Technical Details
- Model: SAID125BX100
- Type: ISO 6432 standard dual-rod pneumatic cylinder
- Bore size: Ø125mm
- Stroke: 100mm (customizable: 25-500mm)
- Operating pressure: 0.05-1.0 MPa
- Temperature range: -20℃ to 80℃
- Cushioning: Adjustable pneumatic cushion (both ends)
- Port size: G1/2 (NPT1/2 optional)
- Mounting: Basic front flange (ISO 15552 MF1)
- Material: Aluminum alloy barrel, chrome-plated piston rod
- Rod diameter: Ø32mm (dual rods)
- Seal material: Nitrile rubber (NBR) with wear-resistant ring
- Repeat positioning accuracy: ±0.5mm
- Max piston speed: 500-800 mm/s
- Protection rating: IP65 (standard wiper seal)
- Lubrication: Pre-lubricated (oil-free operation possible)
- Weight: 3.45 kg (excluding mounting accessories)
- Dimensions: 200mm(L) × 165mm(W) × 165mm(H) (at mid-stroke position)
High-rigidity dual rod cylinder designed for applications requiring enhanced moment resistance and precise linear motion. Features symmetrical force distribution through parallel rods, with anti-rotation design maintaining payload orientation. The hardened piston rods and triple sealing system ensure durability in high-cycle operations. Compatible with magnetic sensors for position feedback (sensor groove pre-machined).
- Precision press-fit operations in automotive assembly
- Vertical lifting mechanisms in packaging machinery
- Clamping fixtures for CNC machining centers
- Material transfer systems requiring anti-rotation stability
- Automated painting equipment with guided tooling
Installation tip:
Maintain 0.05-0.1mm clearance between rods and load connection points to prevent side load stress.
Use locknuts with 1.2x rated torque for vibration resistance. For vertical mounting, install emergency descent prevention valve.
| Property | Property Value |
|---|---|
| sku | SAID125BX100 |
| Seal Material | Polyurethane |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | PT 1/2 |
| Magnet | Non-magnetic |
| Cushion Stroke | <40mm> |
| Bore Diameter | 125mm |
| Stroke | 100mm |
