Airtac SAID125 Double Rod Cylinder SAID125BX1000
2. Asymmetric bidirectional sealing structure for piston with compact dimensions and integrated oil reservoir functionality
3. Cross-section aluminum alloy tube with tie-rod-free design for superior corrosion resistance; Integrated sensor mounting grooves enable fast and secure sensor installation
4. Smooth adjustable cushioned stroke control mechanism
5. Multiple bore sizes and mounting accessories available for customizable configurations
6. High-temperature resistant seals (operating range: 0~150°C)
Category: Dual Rod Cylinders , Brand: AIRTAC , Series: SAID125
AirTAC SAID125BX1000 Twin Shaft Cylinder Specifications
- Model: SAID125BX1000
- Type: Twin shaft pneumatic cylinder (double rod)
- Bore size: Ø125mm (±0.5mm tolerance)
- Stroke: 1000mm (customizable up to 2000mm)
- Operating pressure: 0.05–0.8 MPa
- Shaft diameter: Ø20mm (hard chrome-plated steel)
- Buffer type: Adjustable pneumatic cushioning (both ends)
- Mounting style: Front flange (ISO 15552 standard), optional foot mounting
- Port size: PT1/2 (G1/2 optional)
- Piston speed: 50–800 mm/s (lubricated condition)
- Temperature range: -20℃ to 80℃
- Seal material: NBR (nitrile rubber), PU option available
- Protection rating: IP65 (standard), IP67 with wiper upgrade
- Weight: 15.2kg (excluding mounting accessories)
- Dimensions:
- Total length: 1150mm (stroke length + 150mm end caps)
- Body diameter: Ø140mm (including mounting flanges)
- Center-to-center shaft distance: 180mm
- Mounting hole pattern: 200×200mm square (M10 threaded)
- Accessories: Magnetic piston (D-M9B sensor compatible), auto switch groove standard
High-rigidity twin shaft cylinder designed for heavy-load applications requiring precise linear motion. Features dual chrome-plated guide rods that eliminate rotational torque, with hardened aluminum alloy end caps for impact resistance. The symmetrical structure ensures balanced force distribution, ideal for long-stroke vertical installations. Requires ISO VG32 hydraulic oil lubrication for optimal performance.
- Automotive production line clamping fixtures
- Plastic injection molding ejection systems
- Steel plate stacking/palletizing machinery
- CNC machine tool workpiece positioning
- Large-format printing press paper feed mechanisms
Installation guidelines:
- Align shafts within 0.2mm parallelism tolerance
- Use flexible couplings for shaft-end load connections
- Install external guides when handling >500kg side loads
- Perform stroke-end cushion adjustment under 0.3MPa pressure
| Property | Property Value |
|---|---|
| sku | SAID125BX1000 |
| Seal Material | Polyurethane |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | PT 1/2 |
| Magnet | Non-magnetic |
| Cushion Stroke | <40mm> |
| Bore Diameter | 125mm |
| Stroke | <1000mm> |
