Airtac SAID125 Double Rod Cylinder SAID125BX1000S
2. Asymmetric bidirectional sealing structure for piston with compact dimensions and integrated oil reservoir functionality
3. Cross-section aluminum alloy tube with tie-rod-free design for superior corrosion resistance; Integrated sensor mounting grooves enable fast and secure sensor installation
4. Smooth adjustable cushioned stroke control mechanism
5. Multiple bore sizes and mounting accessories available for customizable configurations
6. High-temperature resistant seals (operating range: 0~150°C)
Category: Dual Rod Cylinders , Brand: AIRTAC , Series: SAID125
AirTAC SAID125BX1000S Dual Axis Cylinder Specifications
- Model: SAID125BX1000S
- Type: Double rod compact cylinder (ISO 6432 compliant)
- Bore size: Ø125mm ±0.5μm tolerance
- Stroke: 1000mm (customizable 50-2000mm)
- Operating pressure: 0.1-0.9 MPa
- Cushioning: Adjustable pneumatic cushion at both ends
- Mounting style: Basic type (MF1) with NAMUR mounting pattern
- Port size: PT1/2 (G1/2 optional)
- Piston rod thread: M20×1.5 dual-end external thread
- Temperature range: -20℃ to 80℃
- Material:
- Cylinder tube: AL6061-T6 hard anodized
- Piston rod: SCM435 chromed steel (25-30HRC)
- Seals: NBR+PU combination
- Weight: 15.8kg ±5% (excluding accessories)
- Dimensions: 1200mm(L) × 140mm(W) × 140mm(H)
- Protection rating: IP54 (standard wipers)
- Max theoretical force: 883N @0.5MPa (both rods combined)
High-rigidity dual-rod cylinder designed for precision linear motion requiring moment resistance. Features dual chromium-plated piston rods with anti-rotation design, providing 2× higher lateral load capacity than single rod cylinders. Includes magnetic piston (D-M9 sensor compatible) for position feedback. Lubricator-free design with self-compensating wear resistance seals.
- Automated welding equipment position locking
- Heavy-duty clamping fixtures in CNC machining
- Vertical lifting platforms in automotive assembly
- Glass panel transfer systems with anti-twist requirements
- Precision paper guillotine alignment mechanisms
Installation guidelines:
Use alignment jigs during mounting to ensure parallel rod movement.
Apply Loctite 243 to mounting bolts (35-40Nm torque).
Requires 5μm filtered air with automatic drain.
Cycle rate limited to ≤80% duty cycle at max stroke.
| Property | Property Value |
|---|---|
| sku | SAID125BX1000S |
| Seal Material | Polyurethane |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | PT 1/2 |
| Magnet | S-Magnetic |
| Cushion Stroke | <40mm> |
| Bore Diameter | 125mm |
| Stroke | <1000mm> |
