Airtac SAID125 Double Rod Cylinder SAID125BX100S
2. Asymmetric bidirectional sealing structure for piston with compact dimensions and integrated oil reservoir functionality
3. Cross-section aluminum alloy tube with tie-rod-free design for superior corrosion resistance; Integrated sensor mounting grooves enable fast and secure sensor installation
4. Smooth adjustable cushioned stroke control mechanism
5. Multiple bore sizes and mounting accessories available for customizable configurations
6. High-temperature resistant seals (operating range: 0~150°C)
Category: Dual Rod Cylinders , Brand: AIRTAC , Series: SAID125
AirTAC SAID125BX100S Twin Rod Cylinder Technical Details
- Model: SAID125BX100S
- Type: ISO 6432 compliant twin rod cylinder
- Bore size: Ø125mm (4.92")
- Stroke: 100mm (3.94") [Customizable up to 2,000mm]
- Rod diameter: Ø32mm x 2 rods (1.26")
- Operating pressure: 0.1–0.9 MPa (14.5–130.5 PSI)
- Cushioning: Adjustable air cushion at both ends
- Temperature range: -20℃ to 80℃ (-4°F to 176°F)
- Mounting: Basic front flange (NF series) with optional foot/mid trunnion
- Port size: G1/2 (BSPP thread)
- Material:
- Tube: Hard anodized aluminum alloy
- Piston rod: Chrome-plated carbon steel (HRC 45-50)
- Seals: NBR (Nitrile) standard, optional FKM/Viton
- Weight: 5.2kg (11.46 lbs) including rods
- Dimensions:
- Length: 345mm (13.58") [Cylinder body only]
- Extended length: 445mm (17.52") at full stroke
- Width: 148mm (5.83") across mounting flange
- Height: 148mm (5.83") vertical clearance
High-rigidity twin rod cylinder designed for precision linear motion requiring anti-rotation stability. Features dual chromium-plated guide rods with hardened surface treatment (0.02-0.05mm chrome layer) for enhanced wear resistance. The symmetrical force distribution design reduces lateral load on bearings, making it ideal for vertical installations. Includes built-in magnetic slot (D-M9 connector compatible) for position sensing.
- Automated palletizing systems - dual rod stability prevents load rotation
- CNC machine tool clamping mechanisms - precise parallel movement
- Glass handling equipment - smooth motion with cushion adjustment
- Die-casting machine ejectors - high thrust force (2,850N @ 0.5MPa)
- Automotive welding jigs - magnetic sensor integration for position feedback
Installation Best Practice:
Maintain 0.05mm/m alignment tolerance during mounting. Lubricate rods with ISO VG32 hydraulic oil
during initial setup. For vertical use, install air dryer to prevent condensed water accumulation
in lower port. Maximum side load capacity: 1,250N at mid-stroke.
| Property | Property Value |
|---|---|
| sku | SAID125BX100S |
| Seal Material | Polyurethane |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | PT 1/2 |
| Magnet | S-Magnetic |
| Cushion Stroke | <40mm> |
| Bore Diameter | 125mm |
| Stroke | 100mm |
