Airtac SAID125 Double Rod Cylinder SAID125BX105
2. Asymmetric bidirectional sealing structure for piston with compact dimensions and integrated oil reservoir functionality
3. Cross-section aluminum alloy tube with tie-rod-free design for superior corrosion resistance; Integrated sensor mounting grooves enable fast and secure sensor installation
4. Smooth adjustable cushioned stroke control mechanism
5. Multiple bore sizes and mounting accessories available for customizable configurations
6. High-temperature resistant seals (operating range: 0~150°C)
Category: Dual Rod Cylinders , Brand: AIRTAC , Series: SAID125
AirTAC SAID125BX105 Double Rod Cylinder Specifications
- Model: SAID125BX105
- Type: ISO 6432 standard double rod cylinder
- Bore size: Ø125mm (±0.5mm tolerance)
- Stroke: 105mm (customizable up to 2000mm)
- Operating pressure: 0.05–1.0 MPa (7-145 psi)
- Cushion type: Adjustable air cushion (both ends)
- Mounting style: Basic MF1 (optional flange/clevis)
- Port size: G1/2 (NPT1/2 optional)
- Rod material: Hard chrome-plated steel (HRC 45-50)
- Tube material: Anodized aluminum alloy
- Rod diameter: Ø25mm (dual rods)
- Repeat accuracy: ±0.1mm
- Max speed: 500-800mm/s (with cushion)
- Weight: 12.8kg (dry, without accessories)
- Dimensions: 430mm(L) × 145mm(W) × 145mm(H)
- Temperature range: -20℃ to 80℃
- Lubrication: Pre-lubricated (use ISO VG32 oil if needed)
High-rigidity double rod cylinder designed for precision linear motion requiring exceptional side load capacity. Features dual chrome-plated piston rods with anti-rotation design, ideal for applications demanding parallel movement stability. Built-in magnetic piston (D-M9B sensor compatible) for position feedback.
- Automated palletizing systems requiring symmetric force
- Press machine ejection mechanisms
- Glass cutting equipment positioning
- Automotive welding fixture clamping
- Precision grinding machine slides
Installation note:
Ensure proper rod alignment using laser alignment tools (max 0.05mm/m deviation).
Apply initial lubrication every 50km of stroke movement.
Use M10 mounting bolts (grade 8.8 or higher) with 45-55 N·m torque.
| Property | Property Value |
|---|---|
| sku | SAID125BX105 |
| Seal Material | Polyurethane |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | PT 1/2 |
| Magnet | Non-magnetic |
| Cushion Stroke | <40mm> |
| Bore Diameter | 125mm |
| Stroke | 105mm |
