Airtac SAID125 Double Rod Cylinder SAID125BX105S
2. Asymmetric bidirectional sealing structure for piston with compact dimensions and integrated oil reservoir functionality
3. Cross-section aluminum alloy tube with tie-rod-free design for superior corrosion resistance; Integrated sensor mounting grooves enable fast and secure sensor installation
4. Smooth adjustable cushioned stroke control mechanism
5. Multiple bore sizes and mounting accessories available for customizable configurations
6. High-temperature resistant seals (operating range: 0~150°C)
Category: Dual Rod Cylinders , Brand: AIRTAC , Series: SAID125
AirTAC SAID125BX105S Dual Rod Cylinder Specifications
- Model: SAID125BX105S
- Type: Double rod cylinder (ISO 6432 compliant)
- Bore size: Ø125mm (±0.5mm tolerance)
- Stroke: 105mm (customizable 25-300mm)
- Operating pressure: 0.1-0.9 MPa
- Cushioning: Adjustable hydraulic buffer
- Piston rod material: Chrome-plated carbon steel (HRC 45-50)
- Tube material: Hard anodized aluminum alloy
- Seals: HNBR/NBR compound seals (FDA compliant options available)
- Temperature range: -20℃ to 80℃ (extended range with special seals)
- Weight: 5.8kg (without accessories)
- Dimensions: 370mm(L) × 152mm(W) × 152mm(H) (at mid-stroke)
- Port size: G3/8 (NPT1/4 optional)
- Max thrust: 883N @0.5MPa (extend/retract)
- Sensor compatibility: M9/M12 inductive sensors
High-rigidity dual rod cylinder designed for precision alignment applications requiring equal force in both directions. Features anti-rotation dual guide rods (Ø25mm) with PTFE-coated bushings for smooth operation. Integrated mounting slots (ISO 15552) allow multiple configuration options. Rated for 5,000km service life at 0.3m/s speed.
- Automated palletizing systems - dual-direction clamping
- Glass cutting machinery - precision glass plate positioning
- Semiconductor wafer handling - vibration-free linear motion
- Injection molding ejectors - balanced ejection force control
- Automotive welding fixtures - synchronized tooling movement
Installation tip:
Maintain 0.05-0.1mm/mm parallelism tolerance between guide rods and base surface.
Lubricate with ISO VG32 hydraulic oil during initial installation. Allow 15mm
clearance behind end covers for full stroke operation.
| Property | Property Value |
|---|---|
| sku | SAID125BX105S |
| Seal Material | Polyurethane |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | PT 1/2 |
| Magnet | S-Magnetic |
| Cushion Stroke | <40mm> |
| Bore Diameter | 125mm |
| Stroke | 105mm |
