Airtac SAID125 Double Rod Cylinder SAID125BX10S
2. Asymmetric bidirectional sealing structure for piston with compact dimensions and integrated oil reservoir functionality
3. Cross-section aluminum alloy tube with tie-rod-free design for superior corrosion resistance; Integrated sensor mounting grooves enable fast and secure sensor installation
4. Smooth adjustable cushioned stroke control mechanism
5. Multiple bore sizes and mounting accessories available for customizable configurations
6. High-temperature resistant seals (operating range: 0~150°C)
Category: Dual Rod Cylinders , Brand: AIRTAC , Series: SAID125
AirTAC SAID125BX10S Double Rod Cylinder Specifications
- Model: SAID125BX10S (Bore size code: 125)
- Stroke: 10mm (Customizable from 10-300mm)
- Bore diameter: 125mm
- Shaft type: Double chrome-plated steel rods
- Operating pressure: 0.05-1.0 MPa
- Temperature range: -20℃ to 80℃
- Cushioning: Adjustable pneumatic cushion
- Mounting: Side-mounted (Standard MF1)
- Port size: PT1/2 (G1/2 optional)
- Piston rod thread: M14×1.5
- Material: Aluminum alloy body, stainless steel tie rods
- Seal material: NBR (Nitrile rubber)
- Protection rating: IP65 (Dust-proof & water jet resistant)
- Weight: 1.85kg (Base model without accessories)
- Dimensions: 160mm(L) × 50mm(W) × 50mm(H) (Stroke 10mm version)
High-precision industrial cylinder featuring dual hardened piston rods for enhanced rigidity and anti-torsion performance. The staggered piston seal design achieves ≤0.5mm/s creep speed stability. Corrosion-resistant anodized surface treatment with built-in magnetic sensor slots (non-magnetic ring version available). Requires ISO 8573-1:2010 Class 3 compressed air.
- Precision press-fit operations in automotive assembly
- Vertical lifting mechanisms in packaging lines
- Semiconductor wafer handling robots
- High-cycle mold clamping systems (up to 5 million cycles)
- Parallel gripper configurations in pick-and-place systems
Installation note:
Maintain 0.05-0.2mm clearance between rod ends and load during alignment.
Lubricate with ISO VG32 hydraulic oil during initial commissioning.
Maximum side load capacity: 220N at full extension.
| Property | Property Value |
|---|---|
| sku | SAID125BX10S |
| Seal Material | Polyurethane |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | PT 1/2 |
| Magnet | S-Magnetic |
| Cushion Stroke | <40mm> |
| Bore Diameter | 125mm |
| Stroke | <10mm> |
