Airtac SAID125 Double Rod Cylinder SAID125BX110
2. Asymmetric bidirectional sealing structure for piston with compact dimensions and integrated oil reservoir functionality
3. Cross-section aluminum alloy tube with tie-rod-free design for superior corrosion resistance; Integrated sensor mounting grooves enable fast and secure sensor installation
4. Smooth adjustable cushioned stroke control mechanism
5. Multiple bore sizes and mounting accessories available for customizable configurations
6. High-temperature resistant seals (operating range: 0~150°C)
Category: Dual Rod Cylinders , Brand: AIRTAC , Series: SAID125
AirTAC SAID125BX110 Twin Guide Cylinder Technical Details
- Model: SAID125BX110
- Type: Twin rod compact cylinder (double-axis)
- Bore size: Φ125mm
- Stroke: 110mm (standard), customizable up to 500mm
- Operating pressure: 0.05-1.0 MPa
- Operating temperature: -20℃ to 80℃
- Cushion type: Adjustable rubber buffer (both ends)
- Port size: G1/2 (NPT1/2 optional)
- Piston rod material: Hard chrome-plated steel
- Tube material: Aluminum alloy (anodized surface)
- Seal material: NBR/PU (standard), optional FKM
- Weight: 9.8kg ±2% (without accessories)
- Dimensions: 338mm(L) × 162mm(W) × 162mm(H)
- Mounting types: Basic/Flange/Foot (optional brackets)
- ISO standard: 15552 compliant
High-rigidity twin rod cylinder designed for precision linear motion with minimal deflection. Features dual chromium-plated guide rods (Φ25mm) for enhanced lateral load capacity (up to 350N). Integrated anti-rotation mechanism ensures stable tooling plate alignment. Optional magnetic piston version (SAID125BX110-M) available for position sensing.
- Precision press mechanisms in automotive assembly
- Vertical lifting platforms for heavy payloads
- Plastic injection molding machine ejectors
- Automated palletizing systems
- Glass handling equipment with vacuum cups
Installation guidelines:
Maintain parallel alignment between guide rods and motion axis.
Use flexible couplings for rod-end connections. Lubricate with ISO VG32 hydraulic oil
during initial installation. Allow 15mm clearance around cylinder body for heat dissipation.
| Property | Property Value |
|---|---|
| sku | SAID125BX110 |
| Seal Material | Polyurethane |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | PT 1/2 |
| Magnet | Non-magnetic |
| Cushion Stroke | <40mm> |
| Bore Diameter | 125mm |
| Stroke | 110mm |
