Airtac SAID125 Double Rod Cylinder SAID125BX110S
2. Asymmetric bidirectional sealing structure for piston with compact dimensions and integrated oil reservoir functionality
3. Cross-section aluminum alloy tube with tie-rod-free design for superior corrosion resistance; Integrated sensor mounting grooves enable fast and secure sensor installation
4. Smooth adjustable cushioned stroke control mechanism
5. Multiple bore sizes and mounting accessories available for customizable configurations
6. High-temperature resistant seals (operating range: 0~150°C)
Category: Dual Rod Cylinders , Brand: AIRTAC , Series: SAID125
AirTAC SAID125BX110S Twin Rod Cylinder Technical Details
- Model: SAID125BX110S
- Type: ISO 15552 compliant twin rod pneumatic cylinder
- Bore size: Ø125 mm (±0.5mm tolerance)
- Stroke: 110 mm (adjustable cushioning ±5mm)
- Operating pressure: 0.1-0.9 MPa (1-9 bar)
- Piston rod diameter: Ø32mm x 2 rods (chrome-plated 45# steel)
- Cushioning type: Air cushion adjustable via needle valves
- Port size: G1/2 (BSPP female threads)
- Ambient temperature: -20℃ to 80℃ (dry air required below 0℃)
- Speed range: 50-800 mm/s (optimal lubrication required)
- Mounting type: Basic front flange (ISO 15552 MF1)
- Seal material: High-grade NBR (nitrile butadiene rubber)
- Tube material: Anodized aluminum alloy AL6063-T5
- Weight: 6.2 kg (excluding accessories)
- Dimensions: 310mm(L) × 125mm(W) × 150mm(H)
- ISO certification: 6431, VDMA 24562, NFE 49-003
High-rigidity twin rod cylinder engineered for precision linear motion in heavy-duty applications. The dual rod configuration provides enhanced stability against rotational torque and side loads up to 450N·m. Features symmetrical pressure distribution and integrated shock absorbers for smooth stroke termination. Optional magnetic piston version (SAID125BX110S/M) available for position feedback.
- Automated palletizing systems requiring parallel motion control
- Press brake tooling adjustment mechanisms
- Large-format CNC router Z-axis counterbalance systems
- Steel coil handling equipment in rolling mills
- Plastic injection molding machine ejector units
Installation guidelines:
Maintain 0.05mm/m alignment tolerance during mounting.
Lubricate with ISO VG32 hydraulic oil before initial operation.
Recommended maintenance interval: 3,000km stroke distance or annually.
| Property | Property Value |
|---|---|
| sku | SAID125BX110S |
| Seal Material | Polyurethane |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | PT 1/2 |
| Magnet | S-Magnetic |
| Cushion Stroke | <40mm> |
| Bore Diameter | 125mm |
| Stroke | 110mm |
