Airtac SAID160 Double Rod Cylinder SAID160AX1000
2. Features asymmetric bidirectional sealing structure for piston, delivering compact dimensions with integrated oil reservoir design.
3. M-shaped extruded aluminum tube construction eliminates tie rods, offering superior corrosion resistance. Pre-machined sensor slots enable rapid magnetic switch installation.
4. Optimized cushioning adjustment ensures smooth end-stroke deceleration.
5. Multiple cylinder specifications and mounting accessories available for flexible system integration.
6. High-temperature resistant seals accommodate extended operating range: 0°C to 150°C.
Category: Double Rod Cylinders | Brand: AIRTAC | Series: SAID160
AirTAC SAID160AX1000 Dual Rod Cylinder Technical Details
- Model: SAID160AX1000
- Type: Double rod pneumatic cylinder (ISO 6432 compliant)
- Bore size: Ø16 mm
- Stroke: 1000 mm (customizable up to 2000mm)
- Operating pressure: 0.05–1.0 MPa
- Cushioning: Adjustable rubber buffer + shock absorber
- Port size: M5x0.8 (standard), G1/8 optional
- Piston rod thread: M6x1.0 (both ends)
- Operating temperature: -20℃ to 80℃
- Tube material: Aluminum alloy (hard anodized)
- Rod material: Chrome-plated steel (Cr-Mo)
- Seal material: NBR + PU combination
- Weight: ~5.8 kg (with mounting brackets)
- Dimensions: 1100mm(L) × 80mm(W) × 80mm(H) (stroke extended)
- Mounting types: Front flange MF1, rear flange MF2, or side mounts
- Lubrication: Pre-lubricated (relubrication interval: 2000km)
High-rigidity dual rod cylinder designed for precision linear motion in long-stroke applications. Features symmetrical force transmission through parallel rods, minimizing lateral torque deformation. The through-rod design allows easy position sensing integration and enables balanced load distribution. Includes anti-rotation mechanism for enhanced stability in vertical installations.
- Automated material handling systems (conveyor alignment)
- Precision glass cutting machinery
- Semiconductor wafer transfer robots
- Automotive welding fixture positioning
- Textile machinery tension control
- 3D printing gantry systems
Installation guidelines:
For strokes >800mm, use intermediate support brackets every 500mm.
Maintain 0.05-0.15mm/mm parallelism tolerance between rods and guide rails.
Apply ISO VG32 hydraulic oil for relubrication.
- Dual rod design reduces bending moment by 40% vs single rod cylinders
- Low friction coefficient: ≤0.2 (dynamic)
- Maximum piston speed: 1.5 m/s
- Repeat positioning accuracy: ±0.1mm
- Rod deflection: <0.3mm at full extension
| Property | Property Value |
|---|---|
| sku | SAID160AX1000 |
| Seal Material | Polyurethane |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | BSPT 3/4 |
| Magnet | Non-magnetic |
| Cushion Stroke | <50mm> |
| Bore Diameter | 160mm |
| Stroke | <1000mm> |
