Airtac SAID160 Double Rod Cylinder SAID160X1000
2. Features asymmetric bidirectional sealing structure for piston, delivering compact dimensions with integrated oil reservoir design.
3. M-shaped extruded aluminum tube construction eliminates tie rods, offering superior corrosion resistance. Pre-machined sensor slots enable rapid magnetic switch installation.
4. Optimized cushioning adjustment ensures smooth end-stroke deceleration.
5. Multiple cylinder specifications and mounting accessories available for flexible system integration.
6. High-temperature resistant seals accommodate extended operating range: 0°C to 150°C.
Category: Double Rod Cylinders | Brand: AIRTAC | Series: SAID160
AirTAC SAID160X1000 Dual-Rod Cylinder Specifications
- Model: SAID160X1000
- Type: ISO standard dual-rod cylinder (double acting)
- Bore size: 160mm
- Stroke: 1000mm
- Rod diameter: 30mm (both rods)
- Mounting styles: MF1 (front flange), MB1 (rear flange), MP4 (foot-mounted)
- Operating pressure: 0.1–0.9 MPa
- Cushioning: Adjustable pneumatic cushion (both ends)
- Material:
- Tube: Hard anodized aluminum alloy
- Piston rod: Chrome-plated steel (DAC-N)
- Seals: NBR/PU compound
- Temperature range: -20℃ to +80℃
- Weight: 18.6kg (without accessories)
- Dimensions:
- Total length: 1235mm (stroke + end caps)
- Body diameter: 166mm (max outer dimension)
- Mounting width: 68mm (MF1 flange)
- Rod center distance: 200mm (between dual rods)
- Protection rating: IP65 (standard wiper design)
- Max thrust: 11,304N @0.63MPa
High-rigidity dual-piston-rod cylinder designed for applications requiring precise linear motion and anti-rotation stability. Features symmetrical load distribution and enhanced moment resistance through dual-rod configuration. Includes magnetic piston for position sensing compatibility (sensor not included).
- Automated palletizing systems requiring parallel motion
- Press machine ejection mechanisms
- Precision glass cutting equipment
- Automotive welding fixture positioning
- Heavy-duty clamping devices
Installation note:
Maintain alignment tolerance ≤0.2mm/m during mounting. Use rod-end bearings for
applications with angular misalignment. Lubricate with ISO VG32 hydraulic oil
for initial operation. Maximum side load capacity: 1,350N.
| Property | Property Value |
|---|---|
| sku | SAID160X1000 |
| Seal Material | Polyurethane |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | BSPT 3/4 |
| Magnet | Non-magnetic |
| Cushion Stroke | <50mm> |
| Bore Diameter | 160mm |
| Stroke | <1000mm> |
