Airtac SAID160 Double Rod Cylinder SAID160X1000S
2. Features asymmetric bidirectional sealing structure for piston, delivering compact dimensions with integrated oil reservoir design.
3. M-shaped extruded aluminum tube construction eliminates tie rods, offering superior corrosion resistance. Pre-machined sensor slots enable rapid magnetic switch installation.
4. Optimized cushioning adjustment ensures smooth end-stroke deceleration.
5. Multiple cylinder specifications and mounting accessories available for flexible system integration.
6. High-temperature resistant seals accommodate extended operating range: 0°C to 150°C.
Category: Double Rod Cylinders | Brand: AIRTAC | Series: SAID160
AirTAC SAID160X1000S Dual Rod Cylinder Specifications
- Model: SAID160X1000S
- Type: Double rod cylinder (ISO 6432 standard)
- Bore size: Ø16mm
- Stroke: 1000mm (customizable up to 2000mm)
- Operating pressure: 0.05–1.0 MPa (7-145 psi)
- Cushioning: Adjustable pneumatic cushion at both ends
- Mounting style: Basic type (optional flange/clevis mounts)
- Port size: M5x0.8 (Rc1/8 or NPT1/8 optional)
- Piston material: Hard anodized aluminum alloy
- Rod material: Chrome-plated steel (Cr-Mo alloy)
- Seal type: NBR seals (PU optional for high-speed)
- Temperature range: -20℃ to 80℃ (dry air required below 0℃)
- Weight: 2.8kg ±5% (without accessories)
- Dimensions: 1100mm(L) x 32mm(W) x 32mm(H)
- Repeat accuracy: ±0.1mm (with guide rods)
- Max speed: 500mm/s (cushioned)
High-rigidity dual rod cylinder designed for precision linear motion in long-stroke applications. Features symmetrical guide rods that eliminate rotational torque, with chrome-plated piston rods offering 2μm surface roughness for smooth operation. Integrated wear rings prevent metal-to-metal contact. Requires ISO 8573-1:2010 Class 3 compressed air.
- PCB board handling robots
- Glass panel transfer systems
- Automated welding positioners
- Precision coating equipment
- Semiconductor wafer carriers
Installation note:
Maintain parallel alignment of guide rods during mounting. For strokes >800mm,
recommend using intermediate supports every 500mm. Lubricate with ISO VG32
turbine oil if operating >0.5m/s continuously.
| Property | Property Value |
|---|---|
| sku | SAID160X1000S |
| Seal Material | Polyurethane |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | BSPT 3/4 |
| Magnet | S-Magnetic |
| Cushion Stroke | <50mm> |
| Bore Diameter | 160mm |
| Stroke | <1000mm> |
