Airtac SAID160 Double Rod Cylinder SAID160X100S
2. Features asymmetric bidirectional sealing structure for piston, delivering compact dimensions with integrated oil reservoir design.
3. M-shaped extruded aluminum tube construction eliminates tie rods, offering superior corrosion resistance. Pre-machined sensor slots enable rapid magnetic switch installation.
4. Optimized cushioning adjustment ensures smooth end-stroke deceleration.
5. Multiple cylinder specifications and mounting accessories available for flexible system integration.
6. High-temperature resistant seals accommodate extended operating range: 0°C to 150°C.
Category: Double Rod Cylinders | Brand: AIRTAC | Series: SAID160
AirTAC SAID160X100S Double Rod Cylinder Technical Details
- Model: SAID160X100S
- Type: ISO 6432 Standard Double Rod Cylinder
- Bore size: 16mm (0.63")
- Stroke: 100mm (3.94")
- Operating pressure: 0.05-1.0 MPa (7-145 PSI)
- Cushioning: Adjustable rubber buffers (both ends)
- Piston rod diameter: 6mm (0.24") x 2 rods
- Port size: M5x0.8 (standard), optional NPT1/8
- Ambient temperature: -20℃ to 80℃ (-4°F to 176°F)
- Material: Aluminum alloy barrel, hard chrome-plated rods
- Seal type: NBR seals with wear-resistant rings
- Weight: 1.8kg (3.97 lbs) ±5%
- Dimensions: 200mm(L) × 80mm(W) × 80mm(H)
- Rod parallelism: ≤0.1mm/100mm stroke
- Repeat accuracy: ±0.2mm
- Dust protection: Built-in scraper seals
Precision dual-rod pneumatic cylinder designed for applications requiring enhanced lateral force resistance and precise linear motion. Features symmetrical load distribution through twin piston rods, making it ideal for clamping fixtures and alignment-critical operations. Includes magnetic piston for sensor compatibility (sensors sold separately).
- PCB board pressing mechanisms
- Glass panel alignment systems
- Precision welding jigs
- Automated optical inspection (AOI) equipment
- Semiconductor wafer handling
- Pharmaceutical tablet compression machines
Installation recommendations:
Maintain 0.5-1mm clearance between rods and external guides. Lubricate with ISO VG32 hydraulic oil
during initial installation. Avoid side loads exceeding 15N. For vertical mounting, use counterbalance valves.
| Property | Property Value |
|---|---|
| sku | SAID160X100S |
| Seal Material | Polyurethane |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | BSPT 3/4 |
| Magnet | S-Magnetic |
| Cushion Stroke | <50mm> |
| Bore Diameter | 160mm |
| Stroke | 100mm |
