Airtac SAID160 Double Rod Cylinder SAID160X105S
2. Features asymmetric bidirectional sealing structure for piston, delivering compact dimensions with integrated oil reservoir design.
3. M-shaped extruded aluminum tube construction eliminates tie rods, offering superior corrosion resistance. Pre-machined sensor slots enable rapid magnetic switch installation.
4. Optimized cushioning adjustment ensures smooth end-stroke deceleration.
5. Multiple cylinder specifications and mounting accessories available for flexible system integration.
6. High-temperature resistant seals accommodate extended operating range: 0°C to 150°C.
Category: Double Rod Cylinders | Brand: AIRTAC | Series: SAID160
AirTAC SAID160X105S Twin Shaft Cylinder Specifications
- Model: SAID160X105S
- Type: Double rod ISO pneumatic cylinder
- Bore size: 16mm (ID)
- Stroke: 105mm (standard customizable)
- Operating pressure: 0.15–0.8 MPa
- Piston rod diameter: 6mm (chrome-plated steel)
- Cushioning: Adjustable rubber buffers
- Port size: M5x0.8 (dual ports)
- Mounting type: Basic front flange (optional foot/axial mounts)
- Material: Aluminum barrel, stainless steel rods
- Seal type: NBR seals (optional FKM for high temp)
- Temperature range: -20℃ to 80℃
- Weight: 1.2kg ±3% (without accessories)
- Dimensions: 165mm(L) × 42mm(W) × 42mm(H)
- Rod protrusion: 52.5mm per side (at mid-stroke)
- IP rating: IP65 (standard wiper design)
Precision twin-rod cylinder offering symmetrical force output and enhanced rigidity. Features dual anti-rotation shafts for stable linear motion, ideal for applications requiring precise alignment. Integrated magnet slot (optional) for position sensing. Lubrication-free operation with self-retaining seals.
- Precision alignment in PCB handling robots
- Clamping mechanisms in CNC tool changers
- Vertical lifting stages in packaging machines
- Guiding systems for laser cutting platforms
- Automated inspection equipment positioning
Installation note:
Maintain parallel alignment of both shafts during mounting. Use alignment jigs for multi-cylinder setups.
Maximum side load: 15N. Requires 5μm filtered air with 1-5 oil mist (ISO VG32 recommended).
| Property | Property Value |
|---|---|
| sku | SAID160X105S |
| Seal Material | Polyurethane |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | BSPT 3/4 |
| Magnet | S-Magnetic |
| Cushion Stroke | <50mm> |
| Bore Diameter | 160mm |
| Stroke | 105mm |
