Airtac SAID160 Double Rod Cylinder SAID160X120S
$388.00
Regular price
$395.50
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
SAID160X120S
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
ISO 15552 (formerly ISO 6431) Standard Double Rod Cylinder
2. Features asymmetric bidirectional sealing structure for piston, delivering compact dimensions with integrated oil reservoir design.
3. M-shaped extruded aluminum tube construction eliminates tie rods, offering superior corrosion resistance. Pre-machined sensor slots enable rapid magnetic switch installation.
4. Optimized cushioning adjustment ensures smooth end-stroke deceleration.
5. Multiple cylinder specifications and mounting accessories available for flexible system integration.
6. High-temperature resistant seals accommodate extended operating range: 0°C to 150°C.
Category: Double Rod Cylinders | Brand: AIRTAC | Series: SAID160
Installation guidelines:
Use M12×1.75 grade 8.8 mounting bolts with 45-50 N·m torque.
Maintain ≤0.1mm/m alignment tolerance during installation.
Lubricate with ISO VG32 hydraulic oil during initial commissioning.
2. Features asymmetric bidirectional sealing structure for piston, delivering compact dimensions with integrated oil reservoir design.
3. M-shaped extruded aluminum tube construction eliminates tie rods, offering superior corrosion resistance. Pre-machined sensor slots enable rapid magnetic switch installation.
4. Optimized cushioning adjustment ensures smooth end-stroke deceleration.
5. Multiple cylinder specifications and mounting accessories available for flexible system integration.
6. High-temperature resistant seals accommodate extended operating range: 0°C to 150°C.
Category: Double Rod Cylinders | Brand: AIRTAC | Series: SAID160
AirTAC SAID160X120S Dual Rod Cylinder Technical Specifications
- Model: SAID160X120S
- Type: ISO15552 compliant dual-rod cylinder
- Bore size: Ø160mm (6.3")
- Stroke: 120mm (standard stroke, customizable)
- Operating pressure: 0.1–0.9 MPa (14.5–130.5 PSI)
- Temperature range: -20℃ to 80℃ (-4°F to 176°F)
- Cushioning: Adjustable pneumatic cushion (both ends)
- Mounting: Basic front flange (ISO 15552-MF1)
- Port size: G1/2 (NPT1/2 optional)
- Piston rod thread: M20×1.5 (dual rod configuration)
- Cylinder tube material: Aluminum alloy (hard anodized)
- Seal material: NBR + polyurethane hybrid seals
- Protection rating: IP65 (standard), IP67 optional
- Weight: 6.5kg (14.3 lbs) ±3%
- Dimensions:
- Total length: 302mm (11.89")
- Body diameter: Ø172mm (6.77")
- Rod center distance: 140mm (5.51")
- Mounting hole spacing: 200×200mm (7.87×7.87")
- Optional accessories:
- Magnetic sensor (D-M9N series compatible)
- Rod lock kit (SAZQ160)
- Heat-resistant seals (-30℃ to 120℃)
High-rigidity dual rod cylinder designed for precision linear motion requiring exceptional anti-rotation stability. Features twin chrome-plated piston rods (hardness HRC 45-50) with integrated wear bands for reduced side load deflection. The symmetrical force distribution enables 30% higher moment resistance compared to single-rod cylinders.
Industrial Applications:
- Press machine ejection systems (die casting applications)
- Automated welding fixture positioning
- Heavy-duty material clamping in CNC machining centers
- Paper converting equipment (slitter-scorer units)
- Automotive wheel alignment test rigs
Installation guidelines:
Use M12×1.75 grade 8.8 mounting bolts with 45-50 N·m torque.
Maintain ≤0.1mm/m alignment tolerance during installation.
Lubricate with ISO VG32 hydraulic oil during initial commissioning.
Service recommendation:
Replace buffer seals every 500,000 cycles in high-speed applications (>0.5 m/s).
Monitor rod parallelism using 0.02mm precision level when servicing.
| Property | Property Value |
|---|---|
| sku | SAID160X120S |
| Seal Material | Polyurethane |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | BSPT 3/4 |
| Magnet | S-Magnetic |
| Cushion Stroke | <50mm> |
| Bore Diameter | 160mm |
| Stroke | 120mm |
