Airtac SAID160 Double Rod Cylinder SAID160X125S
$388.00
Regular price
$395.50
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
SAID160X125S
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
ISO 15552 (formerly ISO 6431) Standard Double Rod Cylinder
2. Features asymmetric bidirectional sealing structure for piston, delivering compact dimensions with integrated oil reservoir design.
3. M-shaped extruded aluminum tube construction eliminates tie rods, offering superior corrosion resistance. Pre-machined sensor slots enable rapid magnetic switch installation.
4. Optimized cushioning adjustment ensures smooth end-stroke deceleration.
5. Multiple cylinder specifications and mounting accessories available for flexible system integration.
6. High-temperature resistant seals accommodate extended operating range: 0°C to 150°C.
Category: Double Rod Cylinders | Brand: AIRTAC | Series: SAID160
Installation note:
Maintain ≤0.1mm/m alignment tolerance during mounting. Use flexible couplings
when connecting to driven components. For vertical installations,
always install air inlet at lower port to prevent condensation pooling.
2. Features asymmetric bidirectional sealing structure for piston, delivering compact dimensions with integrated oil reservoir design.
3. M-shaped extruded aluminum tube construction eliminates tie rods, offering superior corrosion resistance. Pre-machined sensor slots enable rapid magnetic switch installation.
4. Optimized cushioning adjustment ensures smooth end-stroke deceleration.
5. Multiple cylinder specifications and mounting accessories available for flexible system integration.
6. High-temperature resistant seals accommodate extended operating range: 0°C to 150°C.
Category: Double Rod Cylinders | Brand: AIRTAC | Series: SAID160
AirTAC SAID160X125S Dual Axis Cylinder Specifications
- Model: SAID160X125S
- Type: Double rod compact cylinder (ISO 15552 compliant)
- Bore size: 160 mm
- Stroke: 125 mm (customizable up to 1000mm)
- Operating pressure: 0.05–1.0 MPa
- Cushioning: Adjustable air cushion at both ends
- Port size: G3/8 (NPT1/4 optional)
- Piston rod thread: M20×1.5
- Material: Aluminum alloy barrel, chrome-plated piston rod
- Seal material: Heat-resistant NBR (-20℃ to 100℃)
- Weight: 15.2 kg (±3%)
- Dimensions: 298mm(L) × 160mm(W) × 166mm(H)
- Mounting types: Standard AF/FF series brackets
- Protection rating: IP54 (IP67 with optional wiper)
- Lubrication: Pre-lubricated (ISO VG32 recommended)
High-rigidity dual rod cylinder designed for precision alignment applications requiring exceptional moment resistance. Features dual chromium-plated guide rods (Ø20mm) with anti-rotation design, ensuring parallel movement accuracy within 0.1mm/m. Integrated magnet slot supports position sensing.
Typical Applications:
- Vertical lifting systems in automotive assembly lines
- Precision clamping fixtures for CNC machining centers
- Material handling robots with side-mounted loads
- Press brake tool positioning systems
- Glass panel transfer mechanisms
Installation note:
Maintain ≤0.1mm/m alignment tolerance during mounting. Use flexible couplings
when connecting to driven components. For vertical installations,
always install air inlet at lower port to prevent condensation pooling.
Service cycle: Relubricate every 500km of cumulative travel
or 6 months. Replace cushion seals every 2 million cycles in high-speed
applications (>500mm/s).
| Property | Property Value |
|---|---|
| sku | SAID160X125S |
| Seal Material | Polyurethane |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | BSPT 3/4 |
| Magnet | S-Magnetic |
| Cushion Stroke | <50mm> |
| Bore Diameter | 160mm |
| Stroke | 125mm |
