Airtac SAID160 Double Rod Cylinder SAID160X130S
2. Features asymmetric bidirectional sealing structure for piston, delivering compact dimensions with integrated oil reservoir design.
3. M-shaped extruded aluminum tube construction eliminates tie rods, offering superior corrosion resistance. Pre-machined sensor slots enable rapid magnetic switch installation.
4. Optimized cushioning adjustment ensures smooth end-stroke deceleration.
5. Multiple cylinder specifications and mounting accessories available for flexible system integration.
6. High-temperature resistant seals accommodate extended operating range: 0°C to 150°C.
Category: Double Rod Cylinders | Brand: AIRTAC | Series: SAID160
AirTAC SAID160X130S Twin Shaft Cylinder Technical Details
- Model: SAID160X130S
- Bore size: 16mm (ISO 6432 standard)
- Stroke: 130mm (±1mm tolerance)
- Shaft diameter: 12mm (dual chromium-plated rods)
- Operating pressure: 0.15–0.8 MPa
- Max thrust: 130N at 0.5 MPa
- Cushion type: Adjustable rubber buffer (both ends)
- Mounting style: Basic type (axial foot mounting holes M6×1.0)
- Weight: 1.85kg (with standard accessories)
- Dimensions: 250mm(L) × 80mm(W) × 76mm(H)
- Piston material: Aluminum alloy (hard anodized)
- Seal type: NBR + PU combination seals
- Temperature range: -20℃ to 80℃
- Lubrication: Pre-lubricated (DOP oil compatible)
- Protection rating: IP40 (standard wiper design)
High-rigidity twin rod cylinder featuring anti-rotation stability and precise linear motion. The dual shaft configuration minimizes lateral deflection under moment loads, with chrome-plated piston rods providing wear resistance. Includes magnetic piston for sensor compatibility (SM/SD series sensors). Requires 5μm filtered air with 1-10mg/m³ oil mist.
- Precision clamping fixtures in CNC machining centers
- Vertical lift mechanisms for LCD panel handling
- Packaging machine gripper positioning systems
- Automated welding equipment actuator control
- Semiconductor wafer transfer module drives
Installation guidelines:
Maintain 0.5mm minimum clearance between rods during parallel installations.
For vertical mounting, use locknuts (M12×1.25) to prevent rod rotation.
Lubricate rod ends every 500km of cumulative travel.
| Property | Property Value |
|---|---|
| sku | SAID160X130S |
| Seal Material | Polyurethane |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | BSPT 3/4 |
| Magnet | S-Magnetic |
| Cushion Stroke | <50mm> |
| Bore Diameter | 160mm |
| Stroke | 130mm |
