Airtac SAID160 Double Rod Cylinder SAID160X145S
2. Features asymmetric bidirectional sealing structure for piston, delivering compact dimensions with integrated oil reservoir design.
3. M-shaped extruded aluminum tube construction eliminates tie rods, offering superior corrosion resistance. Pre-machined sensor slots enable rapid magnetic switch installation.
4. Optimized cushioning adjustment ensures smooth end-stroke deceleration.
5. Multiple cylinder specifications and mounting accessories available for flexible system integration.
6. High-temperature resistant seals accommodate extended operating range: 0°C to 150°C.
Category: Double Rod Cylinders | Brand: AIRTAC | Series: SAID160
AirTAC SAID160X145S Dual Rod Cylinder Technical Specifications
- Full model code: SAID160X145S
- Type: Double rod air cylinder (ISO 6432 compliant)
- Bore size: Ø160 mm
- Stroke: 145 mm (customizable up to 500mm)
- Operating pressure: 0.05-1.0 MPa
- Operating temperature: -20℃ to 80℃
- Cushioning: Adjustable air cushion (both ends)
- Seal material: NBR/PU combination
- Port size: G1/2 (BSPP thread)
- Piston rod material: Chrome-plated carbon steel (S45C)
- Rod diameter: Ø25mm (both rods)
- Rod thread: M16×1.5 (both ends)
- Mounting type: Basic (optional flange/bracket)
- Weight: 12.8 kg (dry)
- Dimensions: 638mm(L) × 160mm(W) × 160mm(H)
- Lubrication: Pre-lubricated (use ISO VG32 hydraulic oil)
- Protection rating: IP65 (standard wiper seals)
High-rigidity dual rod cylinder designed for precision linear motion control in heavy-duty applications. Features symmetrical force transmission through parallel rods, providing exceptional resistance to torsional loads. The reinforced aluminum alloy body with hardened end caps ensures durability in continuous operation cycles.
- Automated palletizing systems requiring dual-side force output
- Press machine tooling with precise parallel alignment needs
- Glass manufacturing conveyor positioning
- Automotive welding jig actuation
- Plastic injection molding machine core pulls
Installation guidance:
Maintain ≤0.1mm/m alignment tolerance during mounting. Use flexible couplings
when connecting to guided slides. Perform weekly air filter drainage and
quarterly rod lubrication for optimal performance (3-5 drops ISO VG32 oil
through air ports).
| Property | Property Value |
|---|---|
| sku | SAID160X145S |
| Seal Material | Polyurethane |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | BSPT 3/4 |
| Magnet | S-Magnetic |
| Cushion Stroke | <50mm> |
| Bore Diameter | 160mm |
| Stroke | 145mm |
