Airtac SAID200 Double Rod Cylinder SAID200X1000S
The AirTAC Airtac SAID200 Double Rod Cylinder SAID200X1000S is a genuine double-acting ISO 15552 profile-barrel air cylinder with a Ø200mm bore and 1000mm stroke, G3/4 air ports and adjustable end cushioning. Its standardized mounting interface makes it interchangeable with other ISO 15552 cylinders at the mounting interface.
- BoreØ200 mm
- Stroke1000 mm
- Port sizeG3/4
- Acting typeDouble acting
- Rod threadM36×2
- CushionAdjustable, 50 mm
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac SAID200 Double Rod Cylinder SAID200X1000S
The AirTAC SAID200X1000-S is a double-acting, double-rod ISO 15552 profile cylinder featuring a 200 mm bore and a 1000 mm stroke. Because a carbon steel rod exits both end covers, the effective piston area is identical on extend and retract, yielding exactly 15079 N of force in each direction at 0.5 MPa (and 21110 N at 0.7 MPa). The integrated -S magnet enables position tracking via AirTAC CMSE reed and DMSE electronic solid-state switches seated in the dual-side sensor grooves.
This through-rod architecture allows engineers to mount the primary workpiece on one end and attach a cam, secondary tool, or limit flag on the opposite rear rod end. The extruded aluminum barrel design is dimensionally interchangeable with other ISO 15552 cylinders, but note that the rear protruding rod requires dedicated clearance. The adjustable air cushions at both ends decelerate the piston near stroke end but do not lock the load if air pressure is lost.
Airtac SAID200 Double Rod Cylinder SAID200X1000S Technical Specifications
| Model | Airtac SAID200 Double Rod Cylinder SAID200X1000S |
|---|---|
| Series | SAI ISO 15552 profile cylinder |
| Bore size | Ø200 mm |
| Stroke | 1000 mm |
| Acting type | Double acting |
| Port size | G3/4 |
| Rod thread | M36×2 |
| Fluid | Air (filtered by 40µm element) |
|---|---|
| Operating pressure | 0.15 – 1.0 MPa |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C |
| Speed range | 30 – 500 mm/s |
| Cushion | Adjustable, 50 mm |
| Max stroke | Up to 1500 mm |
Specifications follow the official AirTAC SAI series datasheet and ISO 15552 dimensions. Confirm against the product label before installation. Port options: G (BSPP) / NPT.
Theoretical Output Force (Ø200mm)
| Pressure | Push force | Pull force |
|---|---|---|
| 0.5 MPa | 15080 N | 15080 N |
| 0.7 MPa | 21111 N | — |
| Max (@1.0 MPa) | 3075 kgf | |
Double-rod model: the rod passes through the rear cover, so both piston faces lose rod area and push is shown at the annular-area value. Actual usable force is lower than theoretical due to friction and back-pressure. Size with a safety margin.
Model Code: Airtac SAID200 Double Rod Cylinder SAID200X1000S
| SAI | ISO 15552 profile-barrel cylinder series. |
|---|---|
| 200 | Bore size in mm. |
| ×1000 | Stroke length in mm. |
| -S | Optional built-in magnet for sensor position sensing. |
Related SAI-family variants: SAID (double rod), SAIJ (adjustable stroke), SAIL (with lock), SAIF (with valve), BSAI (enclasp / clamp-lock), and SAI-S with built-in magnet. Rod material: carbon steel (blank) / SUS420J2 (A) / SUS304 (B); seals: TPU (blank) / Viton H / NBR N.
Where the Airtac SAID200 Double Rod Cylinder SAID200X1000S Is Used
Heavy-Duty Symmetric Pressing
Utilizes the equal 15079 N extend and retract forces at 0.5 MPa to drive heavy stamping or forming tools that require consistent pressure on both forward and return strokes.
Twin-Station Transfer
Mounts a primary workpiece on the front rod and a secondary position flag or cam on the rear rod to synchronize dual-station material handling without torsional deflection.
Anti-Rotation Guiding
Leverages the double-rod configuration to prevent rotational drift on long 1000 mm stroke automated assembly slides, maintaining strict parallelism for multi-axis machining fixtures.
Is the Airtac SAID200 Double Rod Cylinder SAID200X1000S the Right Cylinder?
Select this 200 mm bore model when an application demands immense bidirectional force and high anti-rotation stability, stepping up from the 160 mm bore (which provides 9425 N at 0.5 MPa). The twin-rod design is chosen over a single-rod SAI when a mechanism requires dual-side guidance or a rear-rod cam for secondary actuation. Because the stroke is 1000 mm, the long unsupported carbon steel rod is highly susceptible to side-load bending; always utilize an external guide to prevent binding and premature rod-bearing wear.
For dimensionally interchangeable direct replacements per ISO 15552, match the 200 mm bore, 1000 mm stroke, G3/4 PT tapered ports, and the -S magnet requirement. Mounting options are limited to the SAID subset: Basic, FA, LB, TC, FTC, TCM1, and TCM2 (omitting the FB, CA, CB, and CR accessories used on single-rod variants). If the machine must hold the load vertically without live pressure, pair this cylinder with an external rod lock or explore the SAIL or BSAID series.
Quick checklist
- ✓ Required force at your working pressure
- ✓ Stroke and mounting space
- ✓ Port/thread type (PT/NPT/G)
- ✓ Magnet (-S) for sensors?
- ✓ Side load — consider a guided cylinder
Installation & Maintenance Notes
- check Use clean air filtered to 40µm or finer.
- check Keep within 0.15 – 1.0 MPa operating pressure.
- check Avoid side load on the piston rod.
- check Adjust end cushion screws for smooth stops.
- check Use correct mounting accessory (FA/FB/CA/CB/LB/TC).
- check Installation by qualified personnel per AirTAC docs.
Airtac SAID200 Double Rod Cylinder SAID200X1000S FAQ
Because the rod occupies both sides of the piston, the effective annulus area is identical in both directions. The output force is 15079 N at 0.5 MPa, 21110 N at 0.7 MPa, and 27141 N at 0.9 MPa for both extend and retract strokes.
Yes, the SAID200X1000-S is a profile cylinder built to ISO 15552 mounting interface dimensions, making it a direct replacement for other ISO 15552 double-rod cylinders. Ensure you have adequate rear clearance for the protruding through-rod and use the SAID-specific mounting set (Basic, FA, LB, TC, FTC, TCM1, TCM2).
