Airtac SAID200 Double Rod Cylinder SAID200X115
$525.52
Regular price
$533.02
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
SAID200X115
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
1. ISO15552 (formerly ISO6431) standard cylinder
2. Asymmetric bidirectional sealing structure for piston sealing with compact dimensions and integrated oil reservoir functionality;
3. Cross-shaped aluminum tube construction without tie rods, offering superior corrosion resistance; External sensor mounting grooves enable quick and convenient sensor installation;
4. Smooth adjustable cushioning mechanism for stable operation;
5. Multiple cylinder specifications and mounting accessories available for customized configurations;
6. High-temperature resistant sealing materials ensure operational temperature range of 0-150℃.
Category: Double Rod Cylinder | Brand: AIRTAC | Series: SAID200
Installation protocol:
Ensure perfect rod alignment during mounting to prevent side load. Use flexible couplings when connecting to guided mechanisms. For vertical installations, implement a fail-safe brake system. Lubricate rods monthly with ISO VG32 hydraulic oil in high-cycle applications (＞500,000 cycles/year).
2. Asymmetric bidirectional sealing structure for piston sealing with compact dimensions and integrated oil reservoir functionality;
3. Cross-shaped aluminum tube construction without tie rods, offering superior corrosion resistance; External sensor mounting grooves enable quick and convenient sensor installation;
4. Smooth adjustable cushioning mechanism for stable operation;
5. Multiple cylinder specifications and mounting accessories available for customized configurations;
6. High-temperature resistant sealing materials ensure operational temperature range of 0-150℃.
Category: Double Rod Cylinder | Brand: AIRTAC | Series: SAID200
AirTAC SAID200X115 Twin Rod Cylinder Technical Details
- Model: SAID200X115
- Type: Double-rod cylinder (ISO 15552 standard)
- Bore size: Ø20 mm
- Stroke: 115 mm (±0.5mm tolerance)
- Operating pressure: 0.05–0.9 MPa
- Piston rod diameter: Ø10 mm (chrome-plated steel)
- Cushioning: Adjustable pneumatic cushion at both ends
- Mounting style: Front flange mounting (MF1) with standardized mounting dimensions
- Position detection: Magnet embeddable (SM/SD series sensors compatible)
- Ambient temperature: -20℃ to +80℃
- Seal material: High-grade NBR (Nitrile rubber)
- Tube material: Anodized aluminum alloy
- Weight: 1.25 kg (without accessories)
- Dimensions:
- Total length (L): 195 mm (stroke + end caps)
- Body diameter: Ø32 mm
- Mounting flange width: 60 mm
- Rod center distance: 25 mm
- Air connection: M5x0.8 threaded ports (standard)
- Lubrication: Pre-lubricated (oil-free operation possible)
- ISO certification: 6431, VDMA 24562
Industrial-grade twin rod cylinder designed for precision linear motion requiring enhanced rigidity and moment resistance. Features symmetrical force distribution through dual piston rods, making it ideal for applications demanding high positional accuracy. The hard-anodized barrel ensures exceptional wear resistance in continuous operation cycles.
Key Applications:
- Precision clamping fixtures in CNC machining centers
- Vertical lifting mechanisms for assembly robots
- Parallel gripper actuation systems
- Packaging machine alignment controls
- Automated test equipment position stages
Installation protocol:
Ensure perfect rod alignment during mounting to prevent side load. Use flexible couplings when connecting to guided mechanisms. For vertical installations, implement a fail-safe brake system. Lubricate rods monthly with ISO VG32 hydraulic oil in high-cycle applications (＞500,000 cycles/year).
Performance Features:
- Dual-rod design reduces deflection by 40% compared to single-rod models
- Withstands lateral forces up to 15N at maximum extension
- Maintenance interval: 5,000 km travel distance or 2 years
- Low-friction seals enable speeds up to 1.0 m/s
| Property | Property Value |
|---|---|
| sku | SAID200X115 |
| Seal Material | Polyurethane |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | BSPT 3/4 |
| Magnet | Non-magnetic |
| Cushion Stroke | <50mm> |
| Bore Diameter | <200mm> |
| Stroke | 115mm |
