AirTAC SAI Series · ISO 15552 Cylinder

Airtac SAID200 Double Rod Cylinder SAID200X155S

The AirTAC SAID200 Double Rod Cylinder SAID200X155S is a genuine double-acting ISO 15552 profile-barrel air cylinder with a Ø200mm bore and 155mm stroke, G3/4 air ports and adjustable end cushioning. Its standardized mounting interface makes it interchangeable with other ISO 15552 cylinders at the mounting interface.

  • BoreØ200 mm
  • Stroke155 mm
  • Port sizeG3/4
  • Acting typeDouble acting
  • Rod threadM36×2
  • CushionAdjustable, 50 mm
$569.46 $576.96Save 1% Standard model — ready in 3-5 business days to process and dispatch
Request a Quote
  • No minimum order. A single piece can be ordered.
  • Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
Compare every SAID200 stroke, mounting and version on one page All SAID200 codes →
verified Genuine AirTAC workspace_premium 1-year warranty bolt Reply in 7-8 h

About the Airtac SAID200 Double Rod Cylinder SAID200X155S

The AirTAC SAID200X155-S is a double-acting, double-rod ISO 15552 profile cylinder engineered for heavy-duty symmetrical motion. Because a carbon steel rod exits both end covers, the effective piston area is identical in each direction, yielding an equal extend and retract thrust of 15079 N at 0.5 MPa (up to 27141 N at 0.9 MPa). This specific 155 mm stroke is a non-standard made-to-order length, requiring a brief production lead time.

Fitted with a -S magnet, the barrel features dual-sided sensor grooves compatible with AirTAC CMSE reed and DMSE solid-state switches for precise end-of-stroke detection on both ends. The rear rod extension is ideal for mounting a secondary cam, position flag, or driving a separate mechanism, while simultaneously providing superior anti-rotation guidance for heavy loads compared to a single-rod SAI.

Airtac SAID200 Double Rod Cylinder SAID200X155S Technical Specifications

ModelAirtac SAID200 Double Rod Cylinder SAID200X155S
SeriesSAI ISO 15552 profile cylinder
Bore sizeØ200 mm
Stroke155 mm
Acting typeDouble acting
Port sizeG3/4
Rod threadM36×2
FluidAir (filtered by 40µm element)
Operating pressure0.15 – 1.0 MPa
Proof pressure1.5 MPa
Temperature-20 to +70 °C
Speed range30 – 500 mm/s
CushionAdjustable, 50 mm
Max strokeUp to 1500 mm

Specifications follow the official AirTAC SAI series datasheet and ISO 15552 dimensions. Confirm against the product label before installation. Port options: G (BSPP) / NPT.

Theoretical Output Force (Ø200mm)

PressurePush forcePull force
0.5 MPa15080 N15080 N
0.7 MPa21111 N—
Max (@1.0 MPa)3075 kgf

Double-rod model: the rod passes through the rear cover, so both piston faces lose rod area and push is shown at the annular-area value. Actual usable force is lower than theoretical due to friction and back-pressure. Size with a safety margin.

Model Code: Airtac SAID200 Double Rod Cylinder SAID200X155S

SAIISO 15552 profile-barrel cylinder series.
200Bore size in mm.
×155Stroke length in mm.
-SOptional built-in magnet for sensor position sensing.

Related SAI-family variants: SAID (double rod), SAIJ (adjustable stroke), SAIL (with lock), SAIF (with valve), BSAI (enclasp / clamp-lock), and SAI-S with built-in magnet. Rod material: carbon steel (blank) / SUS420J2 (A) / SUS304 (B); seals: TPU (blank) / Viton H / NBR N.

Where the Airtac SAID200 Double Rod Cylinder SAID200X155S Is Used

precision_manufacturing

Symmetric Press Clamping

Applies 15079 N of equal clamping and release force at 0.5 MPa, ensuring heavy metal workpieces remain perfectly aligned without rotational drift during high-tonnage pressing operations.

sync_alt

Twin-Station Transfer

Drives two independent mechanisms simultaneously by mounting the primary workpiece on the front rod and a secondary position flag or cam on the rear through-rod for synchronized dual-station actuation.

factory

Heavy-Duty Lift Station

Lifts and lowers massive industrial pallets or molds where push and pull speeds must remain identical, leveraging the 200 mm bore's massive 27141 N thrust capacity at 0.9 MPa.

Is the Airtac SAID200 Double Rod Cylinder SAID200X155S the Right Cylinder?

Select this 200 mm bore when an application requires massive bidirectional force that must remain perfectly equal, such as lifting and lowering a heavy symmetric fixture. If you need slightly less thrust, stepping down to the 160 mm bore yields 9425 N each way at 0.5 MPa, but the 200 mm bore is unmatched for maximum payload capacity. As a true ISO 15552 profile cylinder, it serves as a direct replacement for other ISO 15552 double-rod cylinders, utilizing a G3/4 PT port and mounting accessories from the SAID set (Basic, FA, LB, TC, FTC, TCM1, TCM2).

Note that this plain double-rod cylinder does not hold its position or lock the load when air pressure is lost or exhausted; the piston will drift. For fail-safe load holding without live pressure, consider the SAIL (air-released lock) or BSAID (clamp-lock) variants. Although the 155 mm stroke is below the 300 mm threshold where external side-load guides become critical, the substantial weight of the 40 mm twin rods means you must ensure adequate rear-rod clearance and robust mounting to support the extended overall length.

Quick checklist

  • ✓ Required force at your working pressure
  • ✓ Stroke and mounting space
  • ✓ Port/thread type (PT/NPT/G)
  • ✓ Magnet (-S) for sensors?
  • ✓ Side load — consider a guided cylinder
Ask an Engineer

Installation & Maintenance Notes

  • check Use clean air filtered to 40µm or finer.
  • check Keep within 0.15 – 1.0 MPa operating pressure.
  • check Avoid side load on the piston rod.
  • check Adjust end cushion screws for smooth stops.
  • check Use correct mounting accessory (FA/FB/CA/CB/LB/TC).
  • check Installation by qualified personnel per AirTAC docs.

Airtac SAID200 Double Rod Cylinder SAID200X155S FAQ

Because the 40 mm rod occupies both sides of the piston, the effective annulus area is identical in both directions. It delivers an equal push and pull force of 15079 N at 0.5 MPa, 21110 N at 0.7 MPa, and 27141 N at 0.9 MPa.

Yes, the SAID200X155-S is dimensionally interchangeable per ISO 15552 using its G3/4 PT ports and standard mounting set (Basic, FA, LB, TC, FTC, TCM1, TCM2). It serves as a direct replacement for other ISO 15552 profile double-rod cylinders.
