Airtac SAID32 Double Rod Cylinder SAID32X1000
The AirTAC SAID32 Double Rod Cylinder SAID32X1000 is a genuine double-acting ISO 15552 profile-barrel air cylinder with a Ø32mm bore and 1000mm stroke, G1/8 air ports and adjustable end cushioning. Its standardized mounting interface makes it interchangeable with other ISO 15552 cylinders at the mounting interface.
- BoreØ32 mm
- Stroke1000 mm
- Port sizeG1/8
- Acting typeDouble acting
- Rod threadM10×1.25
- CushionAdjustable, 27 mm
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac SAID32 Double Rod Cylinder SAID32X1000
The AirTAC SAID32X1000 is a double-acting, double-rod ISO 15552 profile cylinder featuring a 32mm bore and a 1000mm stroke. Because the piston rod exits both end covers, the effective annulus area is identical on extend and retract, yielding exactly 483 N of force in both directions at 0.7 MPa. This through-rod geometry provides superior anti-rotation guidance compared to a single-rod SAI.
This configuration uses a standard carbon steel rod and PT tapered port threads without a magnet. The rear rod extension is ideal for mounting a position flag or driving a secondary mechanism. Note that a 1000mm stroke exceeds the standard 500mm limit for this bore, making it a non-standard, made-to-order item that requires extra rear-rod clearance.
Airtac SAID32 Double Rod Cylinder SAID32X1000 Technical Specifications
| Model | Airtac SAID32 Double Rod Cylinder SAID32X1000 |
|---|---|
| Series | SAI ISO 15552 profile cylinder |
| Bore size | Ø32 mm |
| Stroke | 1000 mm |
| Acting type | Double acting |
| Port size | G1/8 |
| Rod thread | M10×1.25 |
| Fluid | Air (filtered by 40µm element) |
|---|---|
| Operating pressure | 0.15 – 1.0 MPa |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C |
| Speed range | 30 – 800 mm/s |
| Cushion | Adjustable, 27 mm |
| Max stroke | Up to 1000 mm |
Specifications follow the official AirTAC SAI series datasheet and ISO 15552 dimensions. Confirm against the product label before installation. Port options: G (BSPP) / NPT.
Theoretical Output Force (Ø32mm)
| Pressure | Push force | Pull force |
|---|---|---|
| 0.5 MPa | 346 N | 346 N |
| 0.7 MPa | 484 N | — |
| Max (@1.0 MPa) | 70 kgf | |
Double-rod model: the rod passes through the rear cover, so both piston faces lose rod area and push is shown at the annular-area value. Actual usable force is lower than theoretical due to friction and back-pressure. Size with a safety margin.
Model Code: Airtac SAID32 Double Rod Cylinder SAID32X1000
| SAI | ISO 15552 profile-barrel cylinder series. |
|---|---|
| 32 | Bore size in mm. |
| ×1000 | Stroke length in mm. |
| -S | Optional built-in magnet for sensor position sensing. |
Related SAI-family variants: SAID (double rod), SAIJ (adjustable stroke), SAIL (with lock), SAIF (with valve), BSAI (enclasp / clamp-lock), and SAI-S with built-in magnet. Rod material: carbon steel (blank) / SUS420J2 (A) / SUS304 (B); seals: TPU (blank) / Viton H / NBR N.
Where the Airtac SAID32 Double Rod Cylinder SAID32X1000 Is Used
Symmetric Force Transfer
Drives a transfer carriage with identical 483 N force and speed in both directions, ensuring perfectly synchronized indexing without momentum imbalances.
Anti-Rotation Slides
Uses the twin-rod geometry to guide a vertical lifting slide, preventing torsional twist over the long 1000mm stroke without external shafts.
Through-Rod Sensing
Mounts a mechanical cam or position flag on the rear rod protrusion to trigger external limit switches, keeping the primary work area clear.
Is the Airtac SAID32 Double Rod Cylinder SAID32X1000 the Right Cylinder?
Choose this twin-rod actuator when an application demands equal push and pull forces (483 N each way at 0.7 MPa) or requires dual-side guidance to prevent rotation. If you need less force, there is no smaller bore in the SAID series; if you need more, stepping up to the 40mm bore yields 739 N at 0.7 MPa. Unlike a single-rod SAI, this model supports a secondary cam or sensor flag on the rear rod.
Because the 1000mm stroke is non-standard and exceeds the typical 500mm maximum for a 32mm bore, it is built to order. An unsupported 1000mm stroke subjects the 12mm rod and its bearing to significant bending moments under side loads, so an external linear guide is mandatory. Remember that the adjustable air cushions only decelerate the piston near stroke end; they do not hold the load if air pressure is lost. For position holding without live pressure, consider a SAIL lock cylinder or an external pilot-operated check valve. This model is dimensionally interchangeable per ISO 15552.
Quick checklist
- ✓ Required force at your working pressure
- ✓ Stroke and mounting space
- ✓ Port/thread type (PT/NPT/G)
- ✓ Magnet (-S) for sensors?
- ✓ Side load — consider a guided cylinder
Installation & Maintenance Notes
- check Use clean air filtered to 40µm or finer.
- check Keep within 0.15 – 1.0 MPa operating pressure.
- check Avoid side load on the piston rod.
- check Adjust end cushion screws for smooth stops.
- check Use correct mounting accessory (FA/FB/CA/CB/LB/TC).
- check Installation by qualified personnel per AirTAC docs.
Airtac SAID32 Double Rod Cylinder SAID32X1000 FAQ
Because the rod occupies both sides of the piston, the push and pull forces are equal. This double-rod cylinder outputs 345 N at 0.5 MPa, 483 N at 0.7 MPa, and 621 N at 0.9 MPa in both directions.
Yes, it shares the exact ISO 15552 mounting interface and dimensions with other profile cylinders of the same bore. It uses the standard SAID mounting set (Basic, FA, LB, TC, FTC, TCM1, TCM2) and drops in wherever a twin-rod ISO 15552 footprint is required.
