Airtac SAID32 Double Rod Cylinder SAID32X110S
2、Profiled bidirectional sealing structure for piston with compact dimensions and integrated oil reservoir;
3、Cross-shaped aluminum tubing design eliminates tie rods, enhancing corrosion resistance. External sensor mounting grooves enable quick and convenient installation;
4、Smooth cushioning adjustment mechanism;
5、Available in multiple configurations with compatible mounting accessories;
6、High-temperature resistant sealing materials support operating range of 0–150°C.
Category: Twin Shaft Cylinder , Brand: AirTAC , Series: SAID32
AirTAC SAID32X110S Dual Rod Cylinder Specifications
- Model: SAID32X110S
- Type: ISO 15552 compliant dual-rod cylinder
- Bore size: 32 mm
- Stroke: 110 mm (±1mm tolerance)
- Operating pressure: 0.05–1.0 MPa
- Medium: Dry air (Lubricated operation requires ISO VG32 oil)
- Temperature range: -20℃ to 80℃
- Cushioning: Adjustable pneumatic cushion (both ends)
- Mounting: Standard ISO 15552 mounting grooves
- Port size: G1/8 (M5 optional)
- Material: Aluminum alloy barrel, hard chrome-plated piston rods
- Rod diameter: 12 mm (dual rods)
- Seal material: NBR (Nitrile rubber)
- Accessories: Built-in magnet for magnetic sensor (D-M9NW)
- Weight: 1.35 kg (with rods)
- Dimensions: 200mm(L) × 52mm(W) × 52mm(H) (at mid-stroke)
- Max piston speed: 500–700 mm/s
- ISO standard: 15552 (formerly ISO 6431)
High-rigidity dual rod cylinder designed for precision linear motion requiring enhanced moment resistance. Features symmetrical force distribution through parallel rods and anti-rotation design. The chrome-plated rods with multi-lip seals ensure ≤0.5 mm³/min air leakage. Includes wear-resistant band for smooth operation up to 1 million cycles.
- Precision clamping fixtures in CNC machining centers
- Vertical lifting mechanisms in automated warehouses
- Parallel gripper actuation in robotic systems
- Press-fit operations in electronic assembly lines
- Position locking in glass processing equipment
Installation note:
Maintain 0.5mm minimum clearance between rods during alignment.
For vertical mounting, use locknuts (AN3-LN) to prevent rod sagging.
Lubricate every 3 months under continuous operation.
| Property | Property Value |
|---|---|
| sku | SAID32X110S |
| Seal Material | Polyurethane |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT1/8 |
| Magnet | S-Magnetic |
| Cushion Stroke | 27mm |
| Bore Diameter | <32 mm> |
| Stroke | 110mm |
