Airtac SAID50 Double Rod Cylinder SAID50X110S
2. Piston features an asymmetric bidirectional sealing structure with compact dimensions and oil reservoir functionality;
3. Cross-shaped aluminum tube with rodless design for enhanced corrosion resistance. Integrated sensor mounting grooves enable quick installation of sensors;
4. Smooth cushioning adjustment mechanism ensures stable operation;
5. Multiple specifications and mounting accessories available for flexible customization;
6. High-temperature resistant sealing materials extend operational range to 0~150℃.
Category: Double Rod Cylinder | Brand: AirTAC | Series: SAID50
AirTAC SAID50X110S Dual Rod Cylinder Technical Details
- Model: SAID50X110S
- Bore size: Ø50 mm
- Stroke: 110 mm
- Operating pressure: 0.05–1.0 MPa
- Piston speed: 50–800 mm/s
- Ambient temperature: -20℃ to 80℃
- Cushioning: Adjustable buffer (both ends)
- Port size: G1/8 (Rc1/8 optional)
- Rod diameter: Ø16 mm (dual rods)
- Mounting types: MF1/MF2 front flange, MB1/MB2 rear flange, MFS1 foot mounting
- Material: Aluminum alloy barrel, hard chrome-plated piston rod
- Seal type: NBR + PU combination seals
- Weight: 3.8 kg (with standard accessories)
- Dimensions:
- Total length: 236 mm (stroke 110mm version)
- Body width: 68 mm (including mounting bosses)
- Height: 60 mm (rod excluded)
- Rod length extension: 110mm stroke adds 110mm to retracted length
Precision dual-rod cylinder designed for high moment resistance and parallel movement stability. Features symmetrical force distribution through twin piston rods, making it ideal for applications requiring precise linear motion and minimal deflection. The hardened chrome rods and multi-lip seals ensure durability in contaminated environments.
- Precision press mechanisms in semiconductor handling
- Vertical lifting platforms with guided alignment
- Glass panel polishing equipment
- Automated welding jig positioning
- Pharmaceutical tablet pressing machines
Installation protocol:
Always align rod ends with guided structures using the dual rod design's inherent parallelism.
Lubricate with ISO VG32 hydraulic oil during initial installation. Maintain 0.3mm minimum
clearance between rod ends and adjacent components for thermal expansion.
Critical note:
The dual rod configuration requires simultaneous load attachment to both rods to prevent
asymmetric forces. Never use single-rod loading in this cylinder design.
| Property | Property Value |
|---|---|
| sku | SAID50X110S |
| Seal Material | Polyurethane |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT1/4 |
| Magnet | S-Magnetic |
| Cushion Stroke | 30mm |
| Bore Diameter | <50mm> |
| Stroke | 110mm |
