Airtac SAID63 Double Rod Cylinder SAID63X10
The AirTAC Airtac SAID63 Double Rod Cylinder SAID63X10 is a genuine double-acting ISO 15552 profile-barrel air cylinder with a Ø63mm bore and 10mm stroke, G3/8 air ports and adjustable end cushioning. Its standardized mounting interface makes it interchangeable with other ISO 15552 cylinders at the mounting interface.
- BoreØ63 mm
- Stroke10 mm
- Port sizeG3/8
- Acting typeDouble acting
- Rod threadM16×1.5
- CushionAdjustable, 36 mm
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac SAID63 Double Rod Cylinder SAID63X10
The AirTAC SAID63X10 is a double-acting, double-rod ISO 15552 profile cylinder engineered for short-stroke symmetrical motion. Because the twin rods occupy both sides of the piston, the annulus area is identical in each direction, yielding an equal extend and retract force of 1402 N at 0.5 MPa. This makes it exceptionally predictable for applications requiring balanced push and pull dynamics.
A defining advantage of this through-rod design is the ability to mount a primary workpiece on the front rod end while utilizing the rear protrusion for a cam, position flag, or secondary mechanism. The extruded aluminum barrel features dual sensor grooves, and while this unit lacks a magnet, the grooves are ready for AirTAC CMSE or DMSE switches if added later. It uses a standard carbon steel rod and PT tapered port threads.
Airtac SAID63 Double Rod Cylinder SAID63X10 Technical Specifications
| Model | Airtac SAID63 Double Rod Cylinder SAID63X10 |
|---|---|
| Series | SAI ISO 15552 profile cylinder |
| Bore size | Ø63 mm |
| Stroke | 10 mm |
| Acting type | Double acting |
| Port size | G3/8 |
| Rod thread | M16×1.5 |
| Fluid | Air (filtered by 40µm element) |
|---|---|
| Operating pressure | 0.15 – 1.0 MPa |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C |
| Speed range | 30 – 800 mm/s |
| Cushion | Adjustable, 36 mm |
| Max stroke | Up to 1500 mm |
Specifications follow the official AirTAC SAI series datasheet and ISO 15552 dimensions. Confirm against the product label before installation. Port options: G (BSPP) / NPT.
Theoretical Output Force (Ø63mm)
| Pressure | Push force | Pull force |
|---|---|---|
| 0.5 MPa | 1402 N | 1402 N |
| 0.7 MPa | 1962 N | — |
| Max (@1.0 MPa) | 286 kgf | |
Double-rod model: the rod passes through the rear cover, so both piston faces lose rod area and push is shown at the annular-area value. Actual usable force is lower than theoretical due to friction and back-pressure. Size with a safety margin.
Model Code: Airtac SAID63 Double Rod Cylinder SAID63X10
| SAI | ISO 15552 profile-barrel cylinder series. |
|---|---|
| 63 | Bore size in mm. |
| ×10 | Stroke length in mm. |
| -S | Optional built-in magnet for sensor position sensing. |
Related SAI-family variants: SAID (double rod), SAIJ (adjustable stroke), SAIL (with lock), SAIF (with valve), BSAI (enclasp / clamp-lock), and SAI-S with built-in magnet. Rod material: carbon steel (blank) / SUS420J2 (A) / SUS304 (B); seals: TPU (blank) / Viton H / NBR N.
Where the Airtac SAID63 Double Rod Cylinder SAID63X10 Is Used
Symmetric Force Transfer
Provides perfectly balanced push and pull forces for transferring parts between two stations without speed variations.
Anti-Rotation Slides
The dual-rod construction resists torsional deflection, keeping short-stroke clamping slides perfectly aligned under offset loads.
Rear-rod Cam Actuation
Drives a primary tool on the front stroke while the protruding rear rod end triggers an external mechanical limit switch.
Is the Airtac SAID63 Double Rod Cylinder SAID63X10 the Right Cylinder?
Select this 63 mm bore, 10 mm stroke model when a compact, symmetrical force output is required without the rotational drift common to single-rod cylinders. If your application needs less force, stepping down to the 50 mm bore provides 825 N both ways at 0.5 MPa; conversely, the 80 mm bore offers 2268 N for heavier loads. The twin-rod architecture inherently provides superior anti-rotation guidance compared to the single-rod SAI series.
As a dimensionally interchangeable ISO 15552 cylinder, it serves as a direct replacement using standard mounting accessories (Basic, FA, LB, TC, FTC, TCM1, TCM2). Note that the adjustable air cushions at both ends only decelerate the piston near stroke limits; they do not hold the load. If position holding without live air pressure is required, consider an external pilot-operated check valve or the BSAID clamp-lock variant.
Quick checklist
- ✓ Required force at your working pressure
- ✓ Stroke and mounting space
- ✓ Port/thread type (PT/NPT/G)
- ✓ Magnet (-S) for sensors?
- ✓ Side load — consider a guided cylinder
Installation & Maintenance Notes
- check Use clean air filtered to 40µm or finer.
- check Keep within 0.15 – 1.0 MPa operating pressure.
- check Avoid side load on the piston rod.
- check Adjust end cushion screws for smooth stops.
- check Use correct mounting accessory (FA/FB/CA/CB/LB/TC).
- check Installation by qualified personnel per AirTAC docs.
Airtac SAID63 Double Rod Cylinder SAID63X10 FAQ
Because it is a double-rod cylinder, the push and pull forces are equal. It delivers 1402 N in both directions at 0.5 MPa, 1962 N at 0.7 MPa, and 2523 N at 0.9 MPa.
Yes, the SAID63X10 is dimensionally interchangeable per ISO 15552. You can use it as a direct replacement for other ISO 15552 double-rod profile cylinders, utilizing standard mounting accessories.
