Airtac SAID63 Double Rod Cylinder SAID63X1000S
The AirTAC SAID63 Double Rod Cylinder SAID63X1000S is a genuine double-acting ISO 15552 profile-barrel air cylinder with a Ø63mm bore and 1000mm stroke, G3/8 air ports and adjustable end cushioning. Its standardized mounting interface makes it interchangeable with other ISO 15552 cylinders at the mounting interface.
- BoreØ63 mm
- Stroke1000 mm
- Port sizeG3/8
- Acting typeDouble acting
- Rod threadM16×1.5
- CushionAdjustable, 36 mm
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac SAID63 Double Rod Cylinder SAID63X1000S
The AirTAC SAID63X1000-S is a double-acting, double-rod ISO 15552 profile cylinder featuring a 63mm bore and a 1000mm non-standard stroke. Because a carbon steel rod exits both end covers, the effective piston area is identical in both directions, yielding an equal extend and retract force of 1402N at 0.5 MPa. The integrated -S magnet works seamlessly with AirTAC CMSE reed and DMSE solid-state switches mounted in the dual-side sensor grooves.
This through-rod architecture allows you to mount the primary workpiece on one end and a position flag or secondary cam on the rear rod end. Equipped with adjustable air cushions at both ends (36mm cushion length) and PT tapered G3/8 ports, it provides stable anti-rotation guidance for symmetric loads. The extended 1000mm stroke requires careful alignment to prevent rod-bearing bending under lateral stress.
Airtac SAID63 Double Rod Cylinder SAID63X1000S Technical Specifications
| Model | Airtac SAID63 Double Rod Cylinder SAID63X1000S |
|---|---|
| Series | SAI ISO 15552 profile cylinder |
| Bore size | Ø63 mm |
| Stroke | 1000 mm |
| Acting type | Double acting |
| Port size | G3/8 |
| Rod thread | M16×1.5 |
| Fluid | Air (filtered by 40µm element) |
|---|---|
| Operating pressure | 0.15 – 1.0 MPa |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C |
| Speed range | 30 – 800 mm/s |
| Cushion | Adjustable, 36 mm |
| Max stroke | Up to 1500 mm |
Specifications follow the official AirTAC SAI series datasheet and ISO 15552 dimensions. Confirm against the product label before installation. Port options: G (BSPP) / NPT.
Theoretical Output Force (Ø63mm)
| Pressure | Push force | Pull force |
|---|---|---|
| 0.5 MPa | 1402 N | 1402 N |
| 0.7 MPa | 1962 N | — |
| Max (@1.0 MPa) | 286 kgf | |
Double-rod model: the rod passes through the rear cover, so both piston faces lose rod area and push is shown at the annular-area value. Actual usable force is lower than theoretical due to friction and back-pressure. Size with a safety margin.
Model Code: Airtac SAID63 Double Rod Cylinder SAID63X1000S
| SAI | ISO 15552 profile-barrel cylinder series. |
|---|---|
| 63 | Bore size in mm. |
| ×1000 | Stroke length in mm. |
| -S | Optional built-in magnet for sensor position sensing. |
Related SAI-family variants: SAID (double rod), SAIJ (adjustable stroke), SAIL (with lock), SAIF (with valve), BSAI (enclasp / clamp-lock), and SAI-S with built-in magnet. Rod material: carbon steel (blank) / SUS420J2 (A) / SUS304 (B); seals: TPU (blank) / Viton H / NBR N.
Where the Airtac SAID63 Double Rod Cylinder SAID63X1000S Is Used
Twin-Station Transfer
Drives two synchronized workstations simultaneously using both rod ends, ensuring perfectly matched speed and equal 1402N force across a 1000mm stroke.
Anti-Rotation Slides
The dual-rod geometry prevents mechanical twisting during long-traverse linear movement, providing superior load guidance compared to a single-rod cylinder.
Rear-Rod Sensing Flag
Mounts a primary tool on the front rod and a cam or DMSE sensor target on the rear protruding rod end to track exact mid-stroke position.
Is the Airtac SAID63 Double Rod Cylinder SAID63X1000S the Right Cylinder?
Choose this specific configuration when an application demands equal bidirectional force and dual-side actuation over a long 1000mm travel. If you need higher force, stepping up to the 80mm bore yields 2268N both ways at 0.5 MPa; for lighter loads, the 50mm bore provides 825N. A double-rod design is preferred over a single-rod SAI when twin-station synchronization or rear-rod position sensing is required. Note that this is a non-standard made-to-order stroke exceeding the 63mm bore's 1500mm maximum standard limit, and the extended rear rod requires additional machine clearance.
Because the 1000mm stroke is highly extended, the unsupported load is susceptible to side-load bending and rod-bearing wear; always use an external guide rail to support the payload. This cylinder is dimensionally interchangeable per ISO 15552 mounting interfaces and uses the reduced SAID accessory set (Basic, FA, LB, TC, FTC, TCM1, TCM2), omitting FB, CA, CB, and CR. Remember that a plain SAID does not hold its load if air pressure drops; for position holding without live pressure, consider the BSAID clamp-lock variant or an external pilot-operated check valve.
Quick checklist
- ✓ Required force at your working pressure
- ✓ Stroke and mounting space
- ✓ Port/thread type (PT/NPT/G)
- ✓ Magnet (-S) for sensors?
- ✓ Side load — consider a guided cylinder
Installation & Maintenance Notes
- check Use clean air filtered to 40µm or finer.
- check Keep within 0.15 – 1.0 MPa operating pressure.
- check Avoid side load on the piston rod.
- check Adjust end cushion screws for smooth stops.
- check Use correct mounting accessory (FA/FB/CA/CB/LB/TC).
- check Installation by qualified personnel per AirTAC docs.
Airtac SAID63 Double Rod Cylinder SAID63X1000S FAQ
Because the double-rod design subtracts the rod area from both sides of the piston, the force is equal in both directions. It provides 1402N at 0.5 MPa, 1962N at 0.7 MPa, and 2523N at 0.9 MPa.
Yes, the SAID63X1000-S is dimensionally interchangeable with other ISO 15552 double-rod profile cylinders. It uses the same mounting footprint and G3/8 PT ports, though it uses a reduced mounting accessory set (no FB, CA, CB, or CR).
