AirTAC SAI Series · ISO 15552 Cylinder

Airtac SAID63 Double Rod Cylinder SAID63X120

The AirTAC SAID63 Double Rod Cylinder SAID63X120 is a genuine double-acting ISO 15552 profile-barrel air cylinder with a Ø63mm bore and 120mm stroke, G3/8 air ports and adjustable end cushioning. Its standardized mounting interface makes it interchangeable with other ISO 15552 cylinders at the mounting interface.

  • BoreØ63 mm
  • Stroke120 mm
  • Port sizeG3/8
  • Acting typeDouble acting
  • Rod threadM16×1.5
  • CushionAdjustable, 36 mm
$105.37 $112.87Save 6% Standard model — usually dispatched in 3-5 days
Request a Quote
  • No minimum order. A single piece can be ordered.
  • Shipped from our own warehouse: most standard models dispatch in 3–5 days; custom and non-standard models take 8–10 business days. Transit time after that depends on the destination.
Compare every SAID63 stroke, mounting and version on one page All SAID63 codes →
verified Genuine AirTAC workspace_premium 1-year warranty bolt Reply in 7 h

About the Airtac SAID63 Double Rod Cylinder SAID63X120

The AirTAC SAID63X120 is a double-acting, double-rod ISO 15552 profile cylinder featuring a 63mm bore and 120mm stroke. Because a rod extends from both end covers, the annulus area is identical on each side, yielding equal push and pull forces of 1402 N at 0.5 MPa. This symmetric output is perfect for applications requiring consistent dynamics in both travel directions.

The twin-rod architecture allows you to mount the primary workpiece on the front rod end while utilizing the rear protrusion for external cam actuation or position flag triggering. The extruded aluminum barrel includes sensor grooves on both sides, and the standard carbon steel rod threads (M16x1.5) provide robust mounting interfaces for your tooling plates.

Airtac SAID63 Double Rod Cylinder SAID63X120 Technical Specifications

ModelAirtac SAID63 Double Rod Cylinder SAID63X120
SeriesSAI ISO 15552 profile cylinder
Bore sizeØ63 mm
Stroke120 mm
Acting typeDouble acting
Port sizeG3/8
Rod threadM16×1.5
FluidAir (filtered by 40µm element)
Operating pressure0.15 – 1.0 MPa
Proof pressure1.5 MPa
Temperature-20 to +70 °C
Speed range30 – 800 mm/s
CushionAdjustable, 36 mm
Max strokeUp to 1500 mm

Specifications follow the official AirTAC SAI series datasheet and ISO 15552 dimensions. Confirm against the product label before installation. Port options: G (BSPP) / NPT.

Theoretical Output Force (Ø63mm)

PressurePush forcePull force
0.5 MPa1402 N1402 N
0.7 MPa1962 N—
Max (@1.0 MPa)286 kgf

Double-rod model: the rod passes through the rear cover, so both piston faces lose rod area and push is shown at the annular-area value. Actual usable force is lower than theoretical due to friction and back-pressure. Size with a safety margin.

Model Code: Airtac SAID63 Double Rod Cylinder SAID63X120

SAIISO 15552 profile-barrel cylinder series.
63Bore size in mm.
×120Stroke length in mm.
-SOptional built-in magnet for sensor position sensing.

Related SAI-family variants: SAID (double rod), SAIJ (adjustable stroke), SAIL (with lock), SAIF (with valve), BSAI (enclasp / clamp-lock), and SAI-S with built-in magnet. Rod material: carbon steel (blank) / SUS420J2 (A) / SUS304 (B); seals: TPU (blank) / Viton H / NBR N.

Where the Airtac SAID63 Double Rod Cylinder SAID63X120 Is Used

sync_alt

Symmetric Force Transfer

Drives a shuttle mechanism where the matching extend and retract speeds prevent jerky transitions, ensuring smooth material handoff between stations.

straighten

Anti-Rotation Slides

The twin-rod geometry keeps the attached tooling plate perfectly aligned under load, preventing torsional deflection during vertical pressing tasks.

settings_input_component

Rear-End Sensing

Mounts the primary tool on the front rod while using the rear protrusion to trigger a physical limit flag or cam for secondary sequence validation.

Is the Airtac SAID63 Double Rod Cylinder SAID63X120 the Right Cylinder?

Select this 63mm bore model when a project demands 1402 N of bidirectional force at 0.5 MPa, stepping up from the 50mm bore (825 N) for heavier symmetric loads, or down from the 80mm bore (2268 N) to save space. A double-rod design is specifically chosen over a single-rod SAI when the mechanism requires dual-side guidance to prevent rotation, or needs rear-end position sensing via CMSE or DMSE switches.

As a dimensionally interchangeable ISO 15552 component, it supports PT ported G3/8 connections and mounts via Basic, FA, LB, TC, FTC, TCM1, or TCM2 accessories (omitting FB/CA/CB/CR). Note that the adjustable air cushions only decelerate the piston near stroke end; they do not lock the load. If pneumatic pressure is lost, the cylinder will drift, requiring a SAIL lock or external pilot-operated check valve for position holding.

AirtacDistr lists every SAID63 order code with its price on one page at https://airtacdistr.com/products/airtac-said63-double-rod-iso-cylinder

Quick checklist

  • ✓ Required force at your working pressure
  • ✓ Stroke and mounting space
  • ✓ Port/thread type (PT/NPT/G)
  • ✓ Magnet (-S) for sensors?
  • ✓ Side load — consider a guided cylinder
Ask an Engineer

Installation & Maintenance Notes

  • check Use clean air filtered to 40µm or finer.
  • check Keep within 0.15 – 1.0 MPa operating pressure.
  • check Avoid side load on the piston rod.
  • check Adjust end cushion screws for smooth stops.
  • check Use correct mounting accessory (FA/FB/CA/CB/LB/TC).
  • check Installation by qualified personnel per AirTAC docs.

Airtac SAID63 Double Rod Cylinder SAID63X120 FAQ

Because the rod occupies both sides of the piston, the effective area is equal in both directions. It delivers 1402 N of force at 0.5 MPa, 1962 N at 0.7 MPa, and 2523 N at 0.9 MPa for both extension and retraction.

Yes, the SAID63X120 is dimensionally interchangeable per ISO 15552 standards. You can drop it in as a replacement for other ISO 15552 double-rod profile cylinders, utilizing the standard G3/8 PT port and standard mounting accessories.
