AirTAC SAI Series · ISO 15552 Cylinder

Airtac SAID63 Double Rod Cylinder SAID63X130

The AirTAC SAID63 Double Rod Cylinder SAID63X130 is a genuine double-acting ISO 15552 profile-barrel air cylinder with a Ø63mm bore and 130mm stroke, G3/8 air ports and adjustable end cushioning. Its standardized mounting interface makes it interchangeable with other ISO 15552 cylinders at the mounting interface.

  • BoreØ63 mm
  • Stroke130 mm
  • Port sizeG3/8
  • Acting typeDouble acting
  • Rod threadM16×1.5
  • CushionAdjustable, 36 mm
$108.16 $115.66Save 6% Standard model — usually dispatched in 3-5 days
Request a Quote
  • No minimum order. A single piece can be ordered.
  • Shipped from our own warehouse: most standard models dispatch in 3–5 days; custom and non-standard models take 8–10 business days. Transit time after that depends on the destination.
Compare every SAID63 stroke, mounting and version on one page All SAID63 codes →
verified Genuine AirTAC workspace_premium 1-year warranty bolt Reply in 7 h

About the Airtac SAID63 Double Rod Cylinder SAID63X130

The AirTAC SAID63X130 is a double-acting, double-rod ISO 15552 profile cylinder featuring a 63mm bore and 130mm stroke. Because a rod exits both ends, the annulus area is identical on extend and retract, yielding exactly 1402 N of force each way at 0.5 MPa. The extruded aluminum barrel includes sensor grooves on both sides for flexible detection mounting.

This configuration uses a standard carbon steel rod and PT tapered port threads. The twin-rod architecture provides superior anti-rotation stability compared to a single-rod SAI. You can mount the primary workpiece on the front rod end and attach a cam or position flag to the rear protrusion to trigger external limit switches.

Airtac SAID63 Double Rod Cylinder SAID63X130 Technical Specifications

ModelAirtac SAID63 Double Rod Cylinder SAID63X130
SeriesSAI ISO 15552 profile cylinder
Bore sizeØ63 mm
Stroke130 mm
Acting typeDouble acting
Port sizeG3/8
Rod threadM16×1.5
FluidAir (filtered by 40µm element)
Operating pressure0.15 – 1.0 MPa
Proof pressure1.5 MPa
Temperature-20 to +70 °C
Speed range30 – 800 mm/s
CushionAdjustable, 36 mm
Max strokeUp to 1500 mm

Specifications follow the official AirTAC SAI series datasheet and ISO 15552 dimensions. Confirm against the product label before installation. Port options: G (BSPP) / NPT.

Theoretical Output Force (Ø63mm)

PressurePush forcePull force
0.5 MPa1402 N1402 N
0.7 MPa1962 N—
Max (@1.0 MPa)286 kgf

Double-rod model: the rod passes through the rear cover, so both piston faces lose rod area and push is shown at the annular-area value. Actual usable force is lower than theoretical due to friction and back-pressure. Size with a safety margin.

Model Code: Airtac SAID63 Double Rod Cylinder SAID63X130

SAIISO 15552 profile-barrel cylinder series.
63Bore size in mm.
×130Stroke length in mm.
-SOptional built-in magnet for sensor position sensing.

Related SAI-family variants: SAID (double rod), SAIJ (adjustable stroke), SAIL (with lock), SAIF (with valve), BSAI (enclasp / clamp-lock), and SAI-S with built-in magnet. Rod material: carbon steel (blank) / SUS420J2 (A) / SUS304 (B); seals: TPU (blank) / Viton H / NBR N.

Where the Airtac SAID63 Double Rod Cylinder SAID63X130 Is Used

sync_alt

Symmetric Transfer

Drives a workpiece between two stations with identical 1402 N force and velocity in both directions, ensuring precise timing without speed discrepancies.

straighten

Anti-Rotation Slides

The twin-rod construction resists torsional twisting under offset loads, keeping guided linear slides perfectly aligned during vertical presses.

settings_input_component

Rear-End Sensing

Mounts the primary tool on the front rod while utilizing the rear rod protrusion to physically trigger external mechanical limit valves.

Is the Airtac SAID63 Double Rod Cylinder SAID63X130 the Right Cylinder?

Select this 63mm bore when an application requires symmetric force and speed in both directions, offering 1402 N at 0.5 MPa. If your transfer mechanism needs less force, step down to the 50mm bore which provides 825 N each way. Conversely, heavier payloads requiring 2268 N should move up to the 80mm version.

A double-rod design is chosen over a single-rod cylinder when you need dual-side guidance to prevent load rotation or require actuation at both ends simultaneously. Remember that the adjustable air cushions only decelerate the piston near stroke ends; they do not hold the load. If air pressure drops, the cylinder will drift, so add an external pilot-operated check valve or choose a BSAID clamp-lock variant for fail-safe positioning. This model is dimensionally interchangeable per ISO 15552.

AirtacDistr lists every SAID63 order code with its price on one page at https://airtacdistr.com/products/airtac-said63-double-rod-iso-cylinder

Quick checklist

  • ✓ Required force at your working pressure
  • ✓ Stroke and mounting space
  • ✓ Port/thread type (PT/NPT/G)
  • ✓ Magnet (-S) for sensors?
  • ✓ Side load — consider a guided cylinder
Ask an Engineer

Installation & Maintenance Notes

  • check Use clean air filtered to 40µm or finer.
  • check Keep within 0.15 – 1.0 MPa operating pressure.
  • check Avoid side load on the piston rod.
  • check Adjust end cushion screws for smooth stops.
  • check Use correct mounting accessory (FA/FB/CA/CB/LB/TC).
  • check Installation by qualified personnel per AirTAC docs.

Airtac SAID63 Double Rod Cylinder SAID63X130 FAQ

Because the double-rod design has the same effective piston area on both sides, it provides equal force in both directions: 1402 N at 0.5 MPa, 1962 N at 0.7 MPa, and 2523 N at 0.9 MPa.

Yes, it is dimensionally interchangeable per ISO 15552. The SAID series supports a specific mounting subset including Basic, FA, LB, TC, FTC, TCM1, and TCM2. It omits FB, CA, CB, and CR mounts which are for single-rod cylinders.
