Airtac SAID63 Double Rod Cylinder SAID63X135S
2. Piston features special-shaped bidirectional sealing structure with compact dimensions and integrated oil reservoir
3. Honeycomb-pattern aluminum tube construction eliminates tie rods, enhancing corrosion resistance. External sensor mounting grooves enable quick installation
4. Smooth cushioning adjustment mechanism
5. Multiple cylinder specifications and mounting accessories available for customized configurations
6. High-temperature resistant sealing materials support operational range of 0-150℃
Category: Double-Axis Cylinder , Brand: AIRTAC , Series: SAID63 （Note: The translation maintains original HTML line breaks while optimizing technical terminology. Key improvements include using "honeycomb-pattern" for structural clarity, "integrated oil reservoir" for functional description, and specifying "operational range" for temperature parameters. Brand name "AIRTAC" is maintained as official English designation.）
AirTAC SAID63X135S Double Rod Cylinder Technical Details
- Model: SAID63X135S
- Type: ISO 15552 compliant double rod cylinder
- Bore size: 63mm
- Stroke: 135mm (customizable 25-600mm)
- Operating pressure: 0.15–0.8 MPa
- Cushioning: Adjustable air cushion (both ends)
- Port size: G1/8 (NPT1/8 optional)
- Rod diameter: 20mm (chromed steel)
- Material: Aluminum barrel with hard anodized finish
- Seals: HNBR/Nitrile compound (-20℃ to 100℃)
- Weight: 4.5kg (with standard mounting brackets)
- Dimensions: 240mm(L) × 80mm(W) × 80mm(H)
- Mounting styles: F1 (front flange), F2 (rear flange), MS1 (side mounts)
- ISO stroke tolerance: ±1.5mm
- Max piston speed: 0.5–1.5 m/s
Precision-engineered twin-rod cylinder featuring symmetrical force distribution and enhanced lateral load capacity. The through-rod design enables position sensing at both ends and prevents rotation during operation. Includes wear-resistant guide bushings and magnetic piston for sensor compatibility. Rated for 5,000km service life under standard conditions.
- Palletizing robot end-effector positioning
- CNC machine tool clamping mechanisms
- Glass cutting table synchronization systems
- Automated conveyor gate actuators
- Precision coating application equipment
Installation guidelines:
Maintain 0.05mm/m alignment tolerance during mounting. Lubricate with ISO VG32 hydraulic oil
during initial installation. Use rod end spherical bearings when angular misalignment exceeds 2°.
| Property | Property Value |
|---|---|
| sku | SAID63X135S |
| Seal Material | Polyurethane |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT3/8 |
| Magnet | S-Magnetic |
| Cushion Stroke | 30mm |
| Bore Diameter | 63mm |
| Stroke | 135mm |
