Airtac SAID63 Double Rod Cylinder SAID63X140S
The AirTAC Airtac SAID63 Double Rod Cylinder SAID63X140S is a genuine double-acting ISO 15552 profile-barrel air cylinder with a Ø63mm bore and 140mm stroke, G3/8 air ports and adjustable end cushioning. Its standardized mounting interface makes it interchangeable with other ISO 15552 cylinders at the mounting interface.
- BoreØ63 mm
- Stroke140 mm
- Port sizeG3/8
- Acting typeDouble acting
- Rod threadM16×1.5
- CushionAdjustable, 36 mm
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac SAID63 Double Rod Cylinder SAID63X140S
The AirTAC SAID63X140-S is a double-acting, double-rod ISO 15552 profile cylinder featuring a through-rod design where a single piston drives rods out of both end covers. Because the annulus area is identical on both sides, it generates an equal 1402 N of force in both extend and retract directions at 0.5 MPa. The included -S magnet enables precise position sensing using AirTAC CMSE reed or DMSE solid-state switches along the dual-side sensor grooves.
Equipped with a 20mm carbon steel rod and M16x1.5 rod thread, this 63mm bore variant uses a G3/8 port and offers adjustable air cushioning at both ends to decelerate the piston smoothly. The twin-rod architecture provides superior anti-rotation guidance and allows the rear rod to operate a secondary mechanism or flag. It uses a reduced mounting accessory set (Basic, FA, LB, TC, FTC, TCM1, TCM2) compared to single-rod SAI types.
Airtac SAID63 Double Rod Cylinder SAID63X140S Technical Specifications
| Model | Airtac SAID63 Double Rod Cylinder SAID63X140S |
|---|---|
| Series | SAI ISO 15552 profile cylinder |
| Bore size | Ø63 mm |
| Stroke | 140 mm |
| Acting type | Double acting |
| Port size | G3/8 |
| Rod thread | M16×1.5 |
| Fluid | Air (filtered by 40µm element) |
|---|---|
| Operating pressure | 0.15 – 1.0 MPa |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C |
| Speed range | 30 – 800 mm/s |
| Cushion | Adjustable, 36 mm |
| Max stroke | Up to 1500 mm |
Specifications follow the official AirTAC SAI series datasheet and ISO 15552 dimensions. Confirm against the product label before installation. Port options: G (BSPP) / NPT.
Theoretical Output Force (Ø63mm)
| Pressure | Push force | Pull force |
|---|---|---|
| 0.5 MPa | 1402 N | 1402 N |
| 0.7 MPa | 1962 N | — |
| Max (@1.0 MPa) | 286 kgf | |
Double-rod model: the rod passes through the rear cover, so both piston faces lose rod area and push is shown at the annular-area value. Actual usable force is lower than theoretical due to friction and back-pressure. Size with a safety margin.
Model Code: Airtac SAID63 Double Rod Cylinder SAID63X140S
| SAI | ISO 15552 profile-barrel cylinder series. |
|---|---|
| 63 | Bore size in mm. |
| ×140 | Stroke length in mm. |
| -S | Optional built-in magnet for sensor position sensing. |
Related SAI-family variants: SAID (double rod), SAIJ (adjustable stroke), SAIL (with lock), SAIF (with valve), BSAI (enclasp / clamp-lock), and SAI-S with built-in magnet. Rod material: carbon steel (blank) / SUS420J2 (A) / SUS304 (B); seals: TPU (blank) / Viton H / NBR N.
Where the Airtac SAID63 Double Rod Cylinder SAID63X140S Is Used
Symmetric Force Transfer
Transfers parts with identical 1402 N push and pull forces, ensuring no speed discrepancy between extension and retraction cycles.
Twin-Station Actuation
Drives a primary workpiece on the front rod while simultaneously moving a secondary mechanism or cam from the rear rod end.
Anti-Rotation Slides
Keeps guided loads perfectly stable without rotational drift, utilizing the dual-rod structure to maintain strict linear alignment.
Is the Airtac SAID63 Double Rod Cylinder SAID63X140S the Right Cylinder?
Choose this double-rod configuration over a standard single-rod SAI when your application demands equal push and pull forces, symmetrical speeds, or dual-side guidance to prevent the load from twisting. If you need less force, the 50mm bore neighbor provides 825 N both ways at 0.5 MPa; if your mechanism requires more power, step up to the 80mm bore for 2268 N. This SAID63X140-S variant includes the -S magnet for CMSE / DMSE sensor integration and uses PT threaded ports.
At a 140mm stroke, the overall length is longer than a single-rod cylinder because the rear rod protrudes through the back cover, so ensure you have adequate clearance for the secondary rod end. Remember that a plain SAID does not hold a load when air pressure is lost; if your mechanism needs static holding, consider the SAIL lock or BSAID clamp-lock series. For stroke lengths of 300mm or more, always add an external guide to prevent rod-bearing bending under side loads.
Quick checklist
- ✓ Required force at your working pressure
- ✓ Stroke and mounting space
- ✓ Port/thread type (PT/NPT/G)
- ✓ Magnet (-S) for sensors?
- ✓ Side load — consider a guided cylinder
Installation & Maintenance Notes
- check Use clean air filtered to 40µm or finer.
- check Keep within 0.15 – 1.0 MPa operating pressure.
- check Avoid side load on the piston rod.
- check Adjust end cushion screws for smooth stops.
- check Use correct mounting accessory (FA/FB/CA/CB/LB/TC).
- check Installation by qualified personnel per AirTAC docs.
Airtac SAID63 Double Rod Cylinder SAID63X140S FAQ
It provides 1402 N of force at 0.5 MPa, 1962 N at 0.7 MPa, and 2523 N at 0.9 MPa. Because it is a double-rod cylinder, this exact force output is identical in both the extend and retract directions.
Yes, it is dimensionally interchangeable per ISO 15552 profile cylinder standards, making it a direct replacement for other ISO 15552 double-rod cylinders. It uses a standard 20mm rod with an M16x1.5 thread.
