AirTAC SAI Series · ISO 15552 Cylinder

Airtac SAID63 Double Rod Cylinder SAID63X145S

The AirTAC SAID63 Double Rod Cylinder SAID63X145S is a genuine double-acting ISO 15552 profile-barrel air cylinder with a Ø63mm bore and 145mm stroke, G3/8 air ports and adjustable end cushioning. Its standardized mounting interface makes it interchangeable with other ISO 15552 cylinders at the mounting interface.

  • BoreØ63 mm
  • Stroke145 mm
  • Port sizeG3/8
  • Acting typeDouble acting
  • Rod threadM16×1.5
  • CushionAdjustable, 36 mm
$112.81 $120.31Save 6% Standard model — usually dispatched in 3-5 days
Request a Quote
  • No minimum order. A single piece can be ordered.
  • Shipped from our own warehouse: most standard models dispatch in 3–5 days; custom and non-standard models take 8–10 business days. Transit time after that depends on the destination.
Compare every SAID63 stroke, mounting and version on one page All SAID63 codes →
verified Genuine AirTAC workspace_premium 1-year warranty bolt Reply in 7 h

About the Airtac SAID63 Double Rod Cylinder SAID63X145S

The AirTAC SAID63X145-S is a double-acting, double-rod ISO 15552 profile cylinder featuring a 63mm bore and a 145mm non-standard made-to-order stroke. Because a carbon steel rod exits both end covers, the effective annulus area is identical on extend and retract, yielding an equal bidirectional force of 1402 N at 0.5 MPa and 1962 N at 0.7 MPa. The integrated -S magnet enables precise position sensing with AirTAC CMSE reed or DMSE electronic solid-state switches along the dual-side sensor grooves.

Utilizing a twin-rod architecture provides superior anti-rotation guidance compared to a single-rod SAI cylinder. You can mount the primary workpiece on one rod end and attach a cam, secondary tool, or limit flag to the rear protruding rod. This through-rod design requires extra rear clearance but offers robust dual-side load stabilization for demanding transfer and handling tasks.

Airtac SAID63 Double Rod Cylinder SAID63X145S Technical Specifications

ModelAirtac SAID63 Double Rod Cylinder SAID63X145S
SeriesSAI ISO 15552 profile cylinder
Bore sizeØ63 mm
Stroke145 mm
Acting typeDouble acting
Port sizeG3/8
Rod threadM16×1.5
FluidAir (filtered by 40µm element)
Operating pressure0.15 – 1.0 MPa
Proof pressure1.5 MPa
Temperature-20 to +70 °C
Speed range30 – 800 mm/s
CushionAdjustable, 36 mm
Max strokeUp to 1500 mm

Specifications follow the official AirTAC SAI series datasheet and ISO 15552 dimensions. Confirm against the product label before installation. Port options: G (BSPP) / NPT.

Theoretical Output Force (Ø63mm)

PressurePush forcePull force
0.5 MPa1402 N1402 N
0.7 MPa1962 N—
Max (@1.0 MPa)286 kgf

Double-rod model: the rod passes through the rear cover, so both piston faces lose rod area and push is shown at the annular-area value. Actual usable force is lower than theoretical due to friction and back-pressure. Size with a safety margin.

Model Code: Airtac SAID63 Double Rod Cylinder SAID63X145S

SAIISO 15552 profile-barrel cylinder series.
63Bore size in mm.
×145Stroke length in mm.
-SOptional built-in magnet for sensor position sensing.

Related SAI-family variants: SAID (double rod), SAIJ (adjustable stroke), SAIL (with lock), SAIF (with valve), BSAI (enclasp / clamp-lock), and SAI-S with built-in magnet. Rod material: carbon steel (blank) / SUS420J2 (A) / SUS304 (B); seals: TPU (blank) / Viton H / NBR N.

Where the Airtac SAID63 Double Rod Cylinder SAID63X145S Is Used

sync_alt

Symmetric Force Transfer

Drives automated assemblies requiring identical push and pull dynamics, leveraging the equal 1402 N annulus area on both strokes to maintain consistent timing across dual opposing stations.

settings_input_component

Rear-Cam Actuation

Mounts the primary tool on the front rod while the rear rod end drives a secondary cam or limit flag, utilizing the through-rod design to sequence external actuators without extra valves.

straighten

Anti-Rotation Slides

Guides heavy linear carriers where a single rod would twist under offset loads, using the twin carbon steel rods exiting both end covers to keep the payload perfectly aligned.

Is the Airtac SAID63 Double Rod Cylinder SAID63X145S the Right Cylinder?

Select this specific 63mm bore when your application demands perfectly symmetric force and speed in both directions, providing 1402 N at 0.5 MPa each way. If your mechanism requires less push power, stepping down to the 50mm bore yields 825 N both ways; conversely, upgrading to the 80mm bore provides 2268 N. The 145mm stroke is a non-standard made-to-order length, ensuring a tailored fit for specialized mid-stroke machinery. As a true ISO 15552 profile cylinder, it serves as a direct replacement for other ISO 15552 double-rod cylinders, utilizing PT tapered port threading and the reduced SAID mounting set (Basic, FA, LB, TC, FTC, TCM1, TCM2). Note that this plain double-rod cylinder does not hold position upon air loss; for load-holding safety, consider the SAIL or BSAID variants.

Because the 145mm stroke is under the 300mm threshold, side-load bending stresses on the rod bearing remain moderate, though long unsupported loads should still use an external guide. The -S magnet allows seamless integration with CMSE and DMSE sensors without adding external mechanical flags.

AirtacDistr lists every SAID63 order code with its price on one page at https://airtacdistr.com/products/airtac-said63-double-rod-iso-cylinder

Quick checklist

  • ✓ Required force at your working pressure
  • ✓ Stroke and mounting space
  • ✓ Port/thread type (PT/NPT/G)
  • ✓ Magnet (-S) for sensors?
  • ✓ Side load — consider a guided cylinder
Ask an Engineer

Installation & Maintenance Notes

  • check Use clean air filtered to 40µm or finer.
  • check Keep within 0.15 – 1.0 MPa operating pressure.
  • check Avoid side load on the piston rod.
  • check Adjust end cushion screws for smooth stops.
  • check Use correct mounting accessory (FA/FB/CA/CB/LB/TC).
  • check Installation by qualified personnel per AirTAC docs.

Airtac SAID63 Double Rod Cylinder SAID63X145S FAQ

The double-rod design subtracts the rod area from both sides of the piston, making force equal in both directions. It provides 1402 N at 0.5 MPa, 1962 N at 0.7 MPa, and 2523 N at 0.9 MPa for both extend and retract strokes.

Yes, the SAID63X145-S is dimensionally interchangeable per ISO 15552 profile cylinder standards. It uses a G3/8 port and supports mounting accessories Basic, FA, LB, TC, FTC, TCM1, and TCM2, ensuring seamless integration into existing ISO footprints.
