Airtac SAID80 Double Rod Cylinder SAID80X1000
2. Piston features specially-shaped bidirectional sealing structure with compact dimensions and integrated oil reservoir capability
3. Cross-reinforced aluminum profile body without tie rods ensures superior corrosion resistance. External sensor mounting grooves enable fast and convenient installation
4. Precision-engineered smooth cushion adjustment mechanism
5. Multiple cylinder specifications and mounting accessories available for flexible configuration
6. High-temperature resistant sealing materials support operational range of 0-150°C
Category: Double Rod Cylinders | Brand: AirTAC | Series: SAID80
AirTAC SAID80X1000 Double Rod Cylinder Technical Specifications
- Model: SAID80X1000
- Type: ISO 15552 compliant double rod pneumatic cylinder
- Bore size: Ø80 mm (±0.1mm manufacturing tolerance)
- Stroke: 1000 mm (customizable from 50-3000mm)
- Operating pressure: 0.05-1.2 MPa (7-174 psi)
- Temperature range: -20℃ to 80℃ (NBR seals)/-10℃ to 70℃ (FKM seals)
- Cushioning: Adjustable air cushion at both ends
- Rod type: Hard chrome-plated steel rods (Ø20mm x2)
- Mounting: Basic MF1 flange + optional foot mounts (ISO 15552)
- Port size: G3/8 (NPT1/4 optional)
- Seal material: Standard NBR (FKM available for high-temp apps)
- Repeat accuracy: ±0.5mm (with guide rods engaged)
- Max speed: 1.0 m/s (with cushioning engaged)
- Weight: 3.8 kg (excluding mounting accessories)
- Dimensions: 1200mm(L) × 160mm(W) × 160mm(H) (stroke extended)
High-rigidity dual guide rod cylinder designed for precision linear motion in heavy-duty applications. Features corrosion-resistant aluminum alloy barrel with double scrape wipers for rod protection. The parallel guide rods (spaced 60mm apart) enable superior moment load resistance - up to 85N·m lateral torque capacity. Includes magnetic piston for position sensing compatibility.
- Automated material handling systems requiring long-stroke precision
- Press brake tool positioning in metal fabrication
- Palletizing robot end-effector guidance
- Semiconductor wafer transfer mechanisms
- Automotive assembly line fixture positioning
Installation guidelines:
Maintain ≤0.1mm/m alignment tolerance during mounting. Lubricate with ISO VG32 hydraulic oil
before initial use. For vertical installations, specify "UP" orientation mark facing upward.
Allow 150mm rear clearance for rod extension maintenance.
| Property | Property Value |
|---|---|
| sku | SAID80X1000 |
| Seal Material | Polyurethane |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT3/8 |
| Magnet | Non-magnetic |
| Cushion Stroke | <36mm> |
| Bore Diameter | 80 mm |
| Stroke | <1000mm> |
