Airtac SAID80 Double Rod Cylinder SAID80X1000S
2. Piston features specially-shaped bidirectional sealing structure with compact dimensions and integrated oil reservoir capability
3. Cross-reinforced aluminum profile body without tie rods ensures superior corrosion resistance. External sensor mounting grooves enable fast and convenient installation
4. Precision-engineered smooth cushion adjustment mechanism
5. Multiple cylinder specifications and mounting accessories available for flexible configuration
6. High-temperature resistant sealing materials support operational range of 0-150°C
Category: Double Rod Cylinders | Brand: AirTAC | Series: SAID80
AirTAC SAID80X1000S Twin Shaft Cylinder Specifications
- Model: SAID80X1000S
- Type: Double rod ISO standard cylinder (Twin axis)
- Bore size: 80 mm
- Stroke: 1000 mm
- Operating pressure: 0.1–0.8 MPa
- Cushioning: Adjustable air cushion (both ends)
- Piston rod material: Hard chrome-plated steel
- Tube material: Anodized aluminum alloy
- Seal material: NBR + Polyurethane (high wear resistance)
- Temperature range: -20℃ to 80℃
- Port size: G1/2 (ISO standard)
- Weight: 9.8 kg (cylinder body only), 12.3 kg (with standard accessories)
- Dimensions:
- Body length: 1295 mm (including stroke)
- Cross-section: 95mm(W) × 95mm(H)
- Center-to-center rod spacing: 60mm
- Rod diameter: 25mm (double rods)
- Max theoretical force: 5024N @0.5MPa
- Protection rating: IP65 (standard), IP67 optional
Heavy-duty twin shaft cylinder designed for precision linear motion requiring high rigidity and torque resistance. Features symmetrical dual piston rods that eliminate rotational torque deviation, making it ideal for long-stroke applications. Pre-lubricated for life with food-grade grease (NSF H1 certified option available). Includes magnetic piston for position sensing compatibility.
- Automated material handling systems
- Press machine guidance mechanisms
- Automotive assembly line positioning
- Glass cutting equipment (horizontal mounting)
- Paper roll tensioning systems
Installation notes:1. Use rigid mounting brackets at both ends for strokes >500mm
2. Align guide rails within 0.2mm/m parallelism tolerance
3. For vertical installations, add external guide supports for strokes exceeding 800mm
4. Lubrication interval: 2000km travel distance or 6 months (whichever comes first)
| Property | Property Value |
|---|---|
| sku | SAID80X1000S |
| Seal Material | Polyurethane |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT3/8 |
| Magnet | S-Magnetic |
| Cushion Stroke | <36mm> |
| Bore Diameter | 80 mm |
| Stroke | <1000mm> |
